| 项目 \ 参数 | C3 | 单位 | | 额定载荷 (Emax): | 1,2.2,4.7,10,22,33,47 | t | | zui大检定分度数(Nlc): | 3000 | d | | zui小检定分度值( Vmin): | 0.01 | % of rated load | | 额定输出 (Cn): | 2.0± 0.1% | mV/V | | *综合误差: | 0.015 | ±% of rated output | | 灵敏度温度影响(Tkc): | 0.0012 | ±% of rated output/°C | | 零点温度影响(Tk0): | 0.0008 | ±% of rated output/°C | | 零点平衡: | 1.0 | ±% of rated output | | 输入阻抗: | 775 5/>=33t:1550±10 | Ω(Ohms) | | 输出阻抗(Ro): | 702 2/>=33t:1402±2 | Ω(Ohms) | | 绝缘电阻: | ≥5000 | MΩ(Mega-Ohms) | | 安全过载: | 150 | % of rated capability | | 极限过载: | 300 | % of rated capability | | 工作温度范围: | -20~+70/-20~+160 | °C / °F | | 推荐工作电压: | 8~24 | V( DC or AC) | | zui大工作电压: | 48 | V( DC or AC) | | 弹性体材料: | Alloy steel / Stainless steel | | 防护等级: | IP67/IP68 |
|
