PD300-TP 以色列OPHIR激光功率计探头PD300-TP

产品名称：以色列OPHIR激光功率计探头PD300-TP

产品型号：PD300-TP

生产厂家：以色列OPHIR

Model：          PD300-TP

Use：            Thin profle for tight ft

Detector Type：    silicon

Aperture：        10x10mm

Filter mode：      Filter out                Filter in

Spectral Range nm：350-1100                430-1100

Power Range：    3mW to 50pW            1W to 200µW

Power Scales：    3mW to 3nW and dBm     1W to 3mW and dBm

Resolution nW：     0.001                  NA

Maximum Power vs.：nm       mW          mW

Wavelength         350-400   100          NA

400-500   100         1000

600       100         1000

700       100         500

800-950   100          300

1064      100         500

Accuracy   (including errors

due to temp. variations)

% error vs Wavelength nm：±7   350-400     NA

                       ±3   400-950     ±5  430-950

                       ±5   950-1100    ±7  950-1100

Damage Threshold W/cm²：10               50

Max Pulse Energy  µJ：   20               100

Noise Level for flter out pW：±2

Response Time with Meter s：0.2

Beam Position Dependence：±2%

Background Subtraction：NA

Fiber Adapters Available(see page 54)：NA

Version：/

Part Number：7Z02424
