PZ41H 闸阀图片系列:PZ41H排渣闸阀

型号
Type

公称通径
DN/mm
Nominal
diameter

主要尺寸/mm Main dimensions

L

D

D1

D2

b

Z-ød

H

PZ41H-10C
PL41H-10C
PZ41H-16C
PL41H-16C
NPZ41H-10C
NPZ41H-16C
电动排渣阀
尺寸同上，
高度重量加电动头。
Dimensions of
motor-driven
valve are the
same as the
above with
extra height

50

250

165

125

102

20

4-ø18

335

80

280

200

150

133

22

8-ø18

510

100

300

220

180

150

24

8-ø18

685

150

350

285

240

212

28

8-ø22

790

200

400

340

295

268

30

12-ø22

885

250

450

405

355

320

32

12-ø26

1015

300

500

460

41O

370

34

12-ø26

1190

350

550

520

470

430

38

16-ø26

1350

400

600

580

525

482

40

16-ø30

1460

500

700

715

650

585

46

20-ø33

1820

　PZ41H-25
PZ941H-25
NPZ41H-25
NPZ941H-25
电动尺寸同上，高度、
重量外加电动装置。
Dimensions
are the same
as the above
With extra
height and
Weight of the
motor

50

250

165

125

102

20

4-ø18

335

80

280

200

150

133

22

8-ø18

510

100

300

235

190

158

24

8-ø22

685

150

350

300

250

212

30

8-ø26

190

200

400

360

31O

278

34

12-ø26

885

250

450

425

370

335

36

12-ø30

1015

300

500

485

430

390

40

16-ø30

1190

350

550

555

490

450

44

16-ø33

1350

400

600

620

550

505

48

16-ø36

1460

450

650

670

600

555

50

20-ø36

1620

500

700

730

660

615

52

20-ø36

1820

PL41H-25
PL941H-25
电动尺寸同上，
高度、重量
外加电动装置。
Dimensions
are the Same
as the above
With extra
height and
Weight of the
mortor

150

400

300

250

212

30

8-ø26

91O

200

500

360

31O

278

34

12-ø26

1100

250

550

425

370

335

36

12-ø30

1430

300

650

485

430

390

40

16-ø30

1558

350

700

555

490

450

44

16-ø33

1678

400

750

620

550

505

48

16-ø36

1830

450

850

670

600

555

50

20-ø36

1990

500

900

730

660

615

52

20-ø36

2160

PZ41H排渣闸阀工作温度
Working temp

≤100℃

PZ41H排渣闸阀阀体材料
Body Material

碳钢WCB
Carbon steel

PZ41H排渣闸阀适用介质
Applicable Media

灰渣水混合物，渣水比≥1:15，zui大类径≤50mm
Mixture of Water and ash residue
With a ratio of residue：Water≥1：15 and max．s
