PRCXI SC8030
Smoke-Detecting Telescope
Product Advantage:PRCXI SC8030 Smoke-Detecting Telescope
Model SC8030 Smoke-Detecting Telescope, simple, quickly and efficiently, Low-cost, improved sensitivity and accuracy, and It is a common method of flue gas emission monitoring.
Des
cription:PRCXI SC8030 Smoke-Detecting Telescope
Model SC8030 Smoke-Detecting Telescope has gathered the universally used standard Ringelman smoke density charts on a piece of glass, thereby to observe the blackness of the smoke. The apparatus can compare the smoke viewed from telescope with the Ringelman smoke density chart directly, and identify the blackness level. The observation is quick and easy to its small volume and portable type, therefore the accuracy is improved.PRCXI SC8030 Smoke-Detecting Telescope
Range of application:
Digital Smoke-Detecting Telescope is widely used in the field of blackness observation and research for enviro
nment protection agencies, enviro
nment mo
nitoring agencies, industrial and mining enterprises and universities all over the world. It can analyze the air pollution level of the flue gas and the utilization rate of the chimney by measuring the smoke blackness, thereby to provide an effective method for enviro
nmental management and energy saving.
Specifications:
1, Ringelman blackness level 0-5.0;
2, View 10 times magnification of telescope;
3, Telescope from 10 to 1000 meters;
4, Objective lens aperture 50 mm;
5, Partition face two-fold magnification camera;
6, Observatio
nal error is not greater than level 0.5.
