7100 系列 7100 系列 实用型耐压/绝缘测试仪
- 型号：7100 系列
- 产地：江苏 苏州市
- 供应商：苏州沁源通贸易有限公司
- 供应商报价： 5700.00￥/台
- 标签：7100 系列 实用型耐压/绝缘测试仪,7100 系列 实用型耐压/绝缘测试仪价格,7100 系列 实用型耐压/绝缘测试仪厂家
产品库
| 类型 | 耐压/绝缘测试仪 | 品Pai | 华仪EXTECH |
| 型号 | 7100 系列 | 测量范围 | 5k（V） |
| 输入电压 | 100~240（V） | 环境温度 | 23（℃） |
| 重量 | 8.4k（g） | 外形尺寸 | 280mm(W)×89mm(H)×300mm(D)（mm） |
| 特点 | |
 | 体积小 (28宽 × 8.9高 × 30深 cm) 、重量轻 8.4kg |
| 四种测试顺序可供选择：W, I, W-I, I-W (Only 7152 , 7162) |
| 可与华仪的接地阻抗测试仪7305连结使用 |
| 内建10组程序内存 |
| 缓升及测试时间可达999.9秒 |
| 键盘锁定功能 |
| 内建PLC Remote可程序遥控界面 |
| 前面板软件输入校正 |
| 操作简单 |
| SPECIFICATIONS | ||||
| MODEL | 7151 | 7152 | 7160 | 7162 |
| AC WITHSTAND VOLTAGE | ||||
| Output Rating | 5KVAC/12mA | |||
| Range | Resolution | Accuracy | ||
| Output Voltage, KVAC | 0-5.00 | 0.01 | ±（2% of setting + 5V） | |
| Output Frequency | 50Hz/60Hz ±100ppm, User Selection | |||
| Output Waveform | Sine Wave ,THD.<2% (Resistive Load), Crest Factor = 1.3 - 1.5 | |||
| Output Regulation | ± (1% of output + 5V), From no load to full load | |||
| SETTINGS | ||||
| Hi-Limit AC Current, mA | 0.10 - 12.00 | 0.01 | ±（2% of setting + 2counts） | |
| Lo-Limit AC Current, mA | 0.00 - 12.00 | 0.01 | ±（2% of setting + 2counts） | |
| Ramp Time, second | 0.1 - 999.9 | 0.1 | ±（0.1% + 0.05sec） | |
| Dwell Time, second | 0, 0.2 - 999.9 (0=continuous) | 0.1 | ||
| Arc Detection | 0, 1 - 9 ranges (0=OFF, 9 is the most sensitivity) | |||
| DC WITHSTAND VOLTAGE (7160,7162 ONLY) | ||||
| Output Rating | 6KVDC/5mA | |||
| Output Voltage, KVDC | 0 - 6.00 | 0.01 | ±（2% of setting + 5V） | |
| Output Ripple | <5%（6KV/5mA at Resistive Load） | |||
| SETTINGS | ||||
| Hi-Limit DC Current, mA | 0.02 - 5.00 | 0.01 | ±（2% of setting + 2counts） | |
| Lo-Limit DC Current, mA | 0.00 - 5.00 | 0.01 | ±（2% of setting + 2counts） | |
| Ramp Time, second | 0.1 - 999.9 | 0.1 | ±（0.1% + 0.05sec） | |
| Dwell Time, second | 0, 0.2 - 999.9 (0=continuous) | 0.1 | ||
| Arc Detection | 0, 1 - 9 ranges (0=OFF, 9 is the most sensitivity) | |||
| Discharge Time | < 200 msec | |||
| INSULATION RESISTANCE (7152,7162 ONLY) | ||||
| Output Rating | 1KVDC/1000MΩ | |||
| Output Voltage, KVDC | 0.10 - 1.00 | 0.01 | ±（2% of setting + 3V） | |
| SETTINGS | ||||
| Hi-Limit Resistance, MΩ | 0, 1 - 1000 (0=OFF) | 1 | ±（3% of setting+2counts）at > 500VDC | |
| Lo-Limit Resistance, MΩ | 1 - 1000 | 1 | ±（7% of setting +2counts）at <500VDC | |
| Delay Time, second | 0, 0.5 - 999.9 (0=continuous) | 0.1 | ±（0.1% + 0.05sec） | |
| MEASUREMENT | ||||
| AC/DC Voltage, KV | 0 - 6.00 | 0.01 | ±（1.5% of reading + 1count） | |
| DC Voltage, KV (IR only) | 0.10 - 1.00 | 0.01 | ±（1.5% of reading + 3V） | |
| AC Current, mA | 0.10 - 12.00 | 0.01 | ±（2% of reading + 2counts） | |
| DC Current, mA | 0.02 - 5.00 | 0.01 | ±（2% of reading + 2counts） | |
| Resistance, MΩ | 1 - 1000 (Auto Range) | 0.001 0.01 0.1 | ±（3% of reading+2counts）at > 500VDC ±（7% of reading +2counts）at <500VDC | |
| GENERAL | ||||
| Input Voltage AC | 115/230Vac±15%, 50/60Hz ± 5%, Fuse 3.1 Fast | |||
| PLC Remote Control | Input : Test , Reset | |||
| Output : Pass , Fail , Processing | ||||
| Memory | 10 Sets Store/Recall of each Memory, 4 Test Mode Selectable （W, I, W～I, I～W Only 7152, 7162） | |||
| Display | 16×2 LCD with back light | |||
| Key Lock | To prevent unauthorized alteration of the test Parameters | |||
| Calibration | Build-in software and external calibrated meters | |||
| Environment | 0-40℃, 20-80%RH | |||
| Dimension/Net Weight | 280mm(W)×89mm(H)×300mm(D)/ 8.4Kg | |||
