PT-50/51/PT-8001/PT-8002/PT-8010/PT-8020/PT-8110/PT-8101/PT-800 台湾差分测试棒PT-50/51

Specifications

Bandwidth

500MHz

Accuracy

±1%

Output Voltage

-Swing(into 50 KΩ load)

±7V

-Offset(typical)

＜±2mV（PT-50），±1ｍV（PT-51）

-Noise(typical)

0.7 m Vrms(PT-50)，1m V rms(PT-51)

-Source Impedance（typical）

50Ω

CMRR(typical)

-90d B@60Hz；-55d B@1MHz

Power Requirements

-Standard

6V DC/90mA or 9VDC/70 mA mains adaptor

-Options

Removable battery Pack or power leads

Length of BNC Lead

125cm

Length of Input Leads

50cm

Weighr

300g

Dimension(L×W×H)

111mm×22mm×14mm

Specifications

PT-50

PT-51

Attenuation Ratio

1/10

1/100

Input Impedance

each side to ground

1.6MΩ//7pF

4MΩ//7pF

Differential Input Voltage

(DC+ Peak AC)

±70V

±700V

Common Mode Voltage

(DC+Peak AC)

±700V

±1400V

Absolute Max .Input

(Each side to ground)

600V rms CATⅠ

600V rms CATⅠ

Features:

·High Accuracy(±1%)

·Best CMRR in Power Measurement Probes

·Safety Certified

Applicstions:

·Precise Power Semicondyctor Device Measurement

·Switching Power Supply Design

·Precise Measurement of Power Converter

·Precise Measurement of Motor Drive
