LA53防爆控制按钮，防爆按钮开关，2钮防爆控制按钮

LA53防爆控制按钮（ⅡC）

 适用范围 Application
1区、2区危险场所。
ⅡA、ⅡB IIC类爆炸性气体环境。
适用于可燃性粉尘场所.
Can be used in Zone 1 and Zone 2 dangerous places.
Can be used in IIA、IIB、IICgroup explosive atmosphere.
Can be used in hammable dust atmosphere.
 型号含义 Main implication

 产品特点 Features
■铸铝合金壳体,表面喷塑.
■整体为复合型结构,外壳采用增安型结构,具有较强的防水,防尘能力
■内装的按钮,指示灯,电流表均为防爆元件.
■钢管或电缆布线均可.
■符合BG3836-2000,IEC60079S标准要求.
◆Diecasted AI-alloy shell,with plastic-spryed surface.
◆Complund structure of safety-increased type.with functions of water-proofing.
◆Dust-proofing inside is arranged button,indicator,Ammeter of explosion-proof types.
◆Suitable for steel pipe and cable wiring.
◆Suitble for BG3836-2000,IEC60079 standard request.

 外形及安装尺寸 Outlinge and installing dimension
        额定电压(V)        额定电流(A)                       防爆标志                   防护等级               进红口螺纹(G")            电缆外径(￠,mm)
       Rated voltage        Rated current                       Ex-mark                      Protection class      Iniet's thread                  Outler's diameter   of cable
-----------------------------------------------------------
   Exed II Bt6          Ip65
             380                          10                *Exed II DIP A20 TA T6           *Ip65                          3/4                                   10-14
 外形举例 Outline example
   CBA53-1    CAB53-2        CBA 53-3     CBA 53-2A
