本系列产品为微波光纤模块（RF over Fiber）,有3GHz, 5GHz, 10GHz, 20GHz等不同带宽的产品，产品可将RF信号转换成光信号，通过光纤传输，接收端再将光信号转换回RF信号。根据需要，可选择单向和双向传输系统。RFoF modules convert RF signals to optical signals and back. One unit has an optical transmitter converts RF to Optical signal, and second receiver unit converts Optical to RF signal. The two units are connected by an optical fiber of the customer.微波光纤模块Applications:• Telecommunication – Antenna remoting , long RF links via fiber• Radar systems微波光纤模块Key features:• Best Cost Performance• Frequency Range: 0.1-20 GHz微波光纤模块Options:• Various RF Gains• Input/output impendence: 50/75 Ohm• Connectors: SMA, N type F type• Electrical interface and Dimensions can be tailored per customer request• Unidirectional or Bidirectional enclosure微波光纤模块简要参数值RF 参数：频率范围：0.1GHz~20GHz;射频增益：-30dB (可选-5dB);1dB压缩点：>20dBm;***大输入RF电平：23dBm;VSWR: 2:1;噪声指数：40dB @1MHz;相位噪声：100dBc/Hz （***小值）；回波损耗：-10dB;输入/输出阻抗：50欧微波光纤模块光学参数：波长：1550nm;出功率：20mW;接收端photodiode工作范围：1200nm~1650nm北京锦坤科技有限公司
www.jonkon.com.cn , www.jon-kon.com
联系电话:010-62530053
