Remote Active Count

Remote Active Count
MicroBiological Air Sample

Designed to meet the industry need for continious trouble free operation and flexible running parameters, the ActiveCountR is the right choice to meet your viable sampling needs. The ActiveCountR can be operated either via local start/stop button or remotely via software interface. Utalizing either a side mount or bottom mount 316L stainless steel impactor, the ActiveCountR offers superior sampling flexiability to meet all of your viable sampling needs. The compact size provides true "plug and play" fuctionality in an easy to use package that quickly integrates into the LMS Pharma or PMS Express real time monitoring systems from Lighthouse.  Whether you are sampling within a cleanroom or inside of a Biosafety Cabinet or Laminr Flow Bench, the ActiveCountP will meet your cGMP compliant monitoring needs. Designed and built by Lighthouse Worldwide Solutions, a name you can trust.



Features	Applications:
Designed for ISO 14698 Compliance 1 CFM (28.3 LPM) sample rate Utilizes an external vacuum system Local start/stop control or remote control via software Stainless steel enclosure Single start/stop push button Local LED status indicators Power Flow Sampling Third party validated sampling head 2 Year warranty	Remote Controlled Cleanroom and Controlled Environment Biocontamination Monitoring Microbial Monitoring in Aseptic Operations Isolator Monitoring Extend Monitoirng of Viable & Non-Viable Particle Levels in One System




Features
Flow rate	1 CFM
Sampling Methodology	Impaction Principle.
Communication Protocol	RS-485 Modbus.
LED Indicators	Power, Flow, Sampling.
User Interface	Manual Start/Stop; Control Software (LMS Pharma, LMS Pro)
Communication Connectors	Switch: Liquid-tite cord grip; Controller: RJ45
Enclosure	Stainless Steel
Sample Outlet Connection	1/4 “ Barb
Vacuum Requirements	16 in HG
Power	24 VDC
Dimensions Impactor	Diameter: 4.41”(11.20 cm), height 2.1“ (5.33 cm)
Dimensions Switch	5.8” (w) x 2.7 (h) x 1.0” (d) [15 x 6.9 x 2.5 cm]
Dimensions Controller	W 8.0“ (w) x 5.0 (h) (20.32 cm), H 5.0” (12.7 cm), D 3.0“ (7.62 cm)
Weight Impactor	Impactor: 4.4 lbs (2.00 kg)
Weight Switch	Switch 0.59 lbs (0.27 kg)
Weight Controller	Controller: 2.6 lbs (1.18 kg)
Environmental Conditions
Operating	50° F to 104° F (10° C to 40° C) / 20% to 95% non-condensing.
Storage	14° F to 122° F (-10° C to 50° C) / Up to 98% non-condensing.
Accessories
Included	Installation guide on CD; power supply, sample tubing.
Optional	Printed installation guide; LMS Express, Express RT software, LMS Pharm software, LMS Pro software
