通过双波长激光，对两个层面的创面血流量进行扫描、记录、分析。
主要用于糖尿病足、周围血管疾病、烧伤、休克等微血管血流量相关疾病的科研、临床工作。
扫描范围：5cm x 5cm up to 50cm x 50cm
the moorldi2 laser doppler blood perfusion imagers use a near infra-red laser beam (785nm in the standard moorldi2-ir imager) or a visible red 633nm laser beam (moorldi2-vr imager). in the moorldi2-2λ dual wavelength system 633 and 830nm lasers are combined to allow simultaneous imaging with the two wavelengths.
the imagers are able to map tissue blood flow over areas from 5cm x 5cm up to 50cm x 50cm with 256 x 256 pixel resolution; - each pixel being an actual measurement. at high scan rates, over 64,000 measurements are made in less than 5 minutes.
the moorldi2 is suitable for a wide range of clinical and research investigations and measurement of blood flow in the microcirculation. the moorldi2 range features a ccd camera which produces a colour image of the scanned area, making the positioning and comparison of images easier. the moorldi2-hr? highest resolution version is available with resolution to 100 microns.
