现货供应德国PTL插座扭矩F37.16

产品信息
现货供应德国PTL插座扭矩F37.16PTL Socket-Outlet Torque Balance


for measuring and testing the torque strain exerted by appliances with plug pins on socket-outlets
 现货供应德国PTL插座扭矩F37.16

PTL Socket-Outlet Torque Balance
for measuring ａnd testing the torque strain exerted by appliances with plug pins on socket-outlets
according to IEC 60065 :2005-12 § 15.4.1 Fig. 11,
IEC 60335-1 :2006-09 § 22.3,
IEC 60884-1 :2006-07 § 14.23.2,
IEC 60950-1 :2005-12 § 4.3.6,
VDE 0620-1 :2005-04 § 14.23.2.
Standard Outfit:
1 testing socket-outlet replica "Euro", two-pole, according to CEE 7, without earth contacts ａnd without protecting rim,
1 testing socket-outlet replica"Schuko", according to CEE 7 standard sheet III,
1 frame for the socket-outlet, pivoted around a horizontal axis through the centre lines of the contact tubes, pivot 8 mm behind the engagement face of the socket-outlet,
1 balance beam, with scale 0 to 0.30 m, rigidly connected with the frame for the socket-outlet,
1 sliding weight, 1 N, lockable, for torques from 0 Nm to 0.30 Nm,
1 counterweight, with screw for fine adjustment, for adjusting the balance beam
1 stop for the balance beam, adjustable ａnd arrest able,
1 trestle with 2 ball bearings ａnd with crossbeam, mounted on a base plate, base plate with adjustable feet ａnd box spirit level.
Design:
Base plate of anodized aluminium, trestle parts black-oxide-finished, balance beam ａnd further parts of stainless steel, base plate approx. 230 mm x 120 mm, balance beam approx. 450 mm, total height approx. 240 mm,
Socket-Outlet Torque Balance Article No.: F 37.16

Accessories:
Socket-outlet Replicas Article No.:
Australia I AS/NZS 3112 250 V / 10 A 3 pol F 37.31
Australia II AS/NZS 3112 250 V / 15 A 3 pol F 37.32
UK I BS 1363,  250 V / 13 A 3 pol F 37.33
UK IIIa BS 546 250 V / 2 A 3 pol F 37.35
US I NEMA 1-15R 125 V / 15 A 2 pol F 37.51
US II NEMA 5-15R 125 V / 15 A 3 pol F 37.52
US III NEMA 5-20R 125 V / 20 A 3 pol F 37.53
US IV NEMA 6-15R 250 V / 15 A 3 pol F 37.54
US V NEMA 6-20R 250 V / 20 A 3 pol F 37.55
