SCD-8系列多路DIN导轨安装温度控制器 SCD-8系列多路DIN导轨安装温度控制器

产品名称:  SCD-8系列多路DIN导轨安装温度控制器
产品型号:  SCD-8多 8 路控制回路, 可选显示
输入: Thermocouple: RTD (depending on model, see Catalog page).
显示: 可选, single row 7 segment LED display, 4 bit PV = Red, SV = Green.
电源: 24 VDC, isolated switching power supply.
电源: 10W + (3W x # of SCD-2000 modules).
操作温度: 32 to 122°F (0 to 50°C).
记忆: 记忆
输出额定: Relay output: SPST 3A @ 250 VAC resistive; Voltage pulse: Output: 24 VDC max, 40 mA; Current output: 4 to 20 mA (resistive load < 500 Ω) (output 1 or 2 only); Linear voltage: 0 to 10 VDC (resistive load > 1000 Ω) (output 1 or 2 only).
通讯: RS-485 Modbus® A-5-11/RTU communication protocol.
重量: 10 oz (425 g).
认证: CE, UL.

EXAMPLE	SCDM-8	0	0	0	LED	Series SCDM-8000-LED Multi-Loop DIN Rail Mount Temperature Controller, 4 thermocouple inputs, with LED display.
SERIES	SCDM-8					Multi-Loop DIN Rail Mount Temperature Controller
INPUT SELECTION		0 1 2 3				4 Thermocouple Inputs 3 RTD Inputs 8 Thermocouple Inputs 6 RTD Inputs
OUTPUT 1 CARD SELECTION			0 2 3 5 6			None Pulsed Voltage Relay Current Linear Voltage
OUTPUT 2 CARD SELECTION				0 2 3 5 6		None Pulsed Voltage Relay Current Linear Voltage
OPTIONS					LED PV	LED Display Pulsed Voltage on Alarm Output Sub 1 & Sub 2
