MRW-6400P 工业电源MRW-6400P

【Mini Redundant】MRW-6400P

400W ATX 2.03,ATX12V(P4),EPS12V,WTX,AMD-GES Server,Workstation,Storage System,IPC

185.00x150.00x86.00 (mm) 7.28x5.91x3.39 (inch) VOLTAGE: 90 ~ 264 VAC FULL RANGE Output Voltage Output Current Min. Output Current Max. Output Current Peak Regulation Load Regulation Line Output Ripple & Noise Max.[P-P] 5V 3 35.00 ± 5% ± 1% 50mV 12V 2 28 ± 6% ± 1% 120mV -5V 0 0.5 ±10% ± 1% 150mV -12V 0 1.2 ±10% ± 1% 150mV 3.3V 1 25 ± 5% ± 1% 50mV +5VSB 0.1 2 ± 5% ± 1% 60mV REMARKS: * NEITHER +5V & + 3.3V NOR +3.3V & 12V SHOULD EXCEED 48 A * TOTAL MAXIMUM OUTPUT OF 5V, 3.3V AND 12V : 378W *Active PFC (full range), MEET IEC-1000-3-2 CLASS D *12V Max. Current : 28A *TEMPERATURE RANGE : OPERATING 0℃ ~ 40℃, STORAGE –20℃ ~ 70℃ * HUMIDITY:OPERATING:20%-95%, NON-OPERATING:10%-95% * REMARKS:85% IS NORMAL CONDITION AND 95% IS WITH SPECIAL COATING PROCESS *EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS

我公司是专做电子盘和工业电源的。电子盘（DOM，DOC，CF卡，SSD）工业电源，宽温硬盘，工控配件等。有需要联系我。
公司名称：北京星研控科技有限责任公司
地址：北京市海淀区海淀大街34号华奥623室
移动：
MSN:
：盛咪
网址：http://www.xingyankong.com
http://www.aprodisk.com
