>>用途说明
该表用于测量对铜和铜合金无腐蚀性、无爆炸性、且不结晶，不沉淀的气体或液体的压力。
>> 主要技术指标
名 称
|
型 号
|
精度等级
|
测量范围
|
使用环境条件
|
温度影响
|
一般压力表
|
Y-40
| 2.5
| 0.1,0.16,0.25,0.4,0.6,1,1.6, 2.5,4,6
|
-40～+70℃；相对湿度不大于85％。
|
使用温度如偏离20±5℃时，其温度附加误差不大于0.4％/10℃
|
Y-60
|
2.5
|
0.1,0.16
0.25,0.4
0.6,1,1.6
2.5,4,6,10
16,25,40
60,100
-0.1～0,-0.1～0.06,
-0.1～0.15,-0.1～0.3
-0.1～0.5,-1～0.9
-0.1～1.5,-0.1～2.4
|
Y-100
|
1.6
|
Y-150
|
1.6
|
Y-200
|
1.6
|
Y-250
|
1.6
|
径向带后边压力表
|
Y-60T
|
2.5
|
Y-100T
|
1.6
|
Y-150T
|
1.6
|
轴向带前边压力表
|
Y-60TZ
|
2.5
|
Y-100TZ
|
1.6
|
Y-150TZ
|
1.6
|
轴向无边压力表
|
Y-40Z
|
2.5
|
Y-60Z
|
2.5
|
Y-100Z
|
1.6
|
Y-150Z
|
1.6
|
径向带后边
|
Y-60T
|
2.5
|
Y-100T
|
1.6
|
Y-150T
|
1.6
|
>>外形尺寸
型号
|
D
|
d
|
d1
|
L
|
d0
|
B
|
H
|
d2
|
H1
|
H2
|
L1
|
Y-40
| φ40
| M10×1
| φ2.5
| 10
| | 38
| 24
| | | 8.5
|
2
|
Y-40Z
| φ40
| M10×1
| φ2.5
| 10
| | 40
| 24
| | | 0
|
2
|
Y-60
| φ60
| M10×1或M14×1.5
| φ5
| 14
| | 56
| 30
| | | 12
| 2
|
Y-60Z
| φ60
| M10×1或M14×1.5
| φ5
| 14
| | 58
| 30
| | | 0
| 2
|
Y-60T
| φ60
| M10×1或M14×1.5
| φ5
| 14
| 72
| 56
| 30
| φ4.5
| | 13
| 2
|
Y-60ZT
| φ60
| M10×1或M14×1.5
| φ5
| 14
| 72
| 53
| 30
| φ4.5
| 24
| 0
| 2
|
Y-100
| φ100
| M20×1.5
| φ6
| 20
| | 90
| 44
| | | 18
| 2
|
Y-100Z
| φ100
| M20×1.5
| φ6
| 20
| | 85
| 44
| | | 30
| 2
|
Y-100T
| φ100
| M20×1.5
| φ6
| 20
| 118
| 90
| 45
| φ5.5
| | 18
| 2
|
Y-100ZT
| φ100
| M20×1.5
| φ6
| 20
| 118
| 85
| 44
| φ5.5
| 39
| 30
| 2
|
Y-150
| φ150
| M20×1.5
| φ6
| 20
| | 115
| 48
| | | 18
| 2
|
Y-150Z
| φ150
| M20×1.5
| φ6
| 20
| | 92
| 47
| | | 30
| 2
|
Y-150T
| φ150
| M20×1.5
| φ6
| 20
| 165
| 115
| 48
| φ5.5
| | 18
| 2
|
Y-150ZT
| φ150
| M20×1.5
| φ6
| 20
| 165
| 92
| 47
| φ5.5
| 41
| 30
| 2
|
Y-200
| φ200
| M20×1.5
| φ6
| 20
| | 146
| 50
| | | 18
| 2
|
Y-250
| φ200
| M20×1.5
| φ6
| 20
| | 167
| 50
| | | 18
| 2
|
|
|
