TCPA300电流放大器 TCP312 电流探头 TCP305 泰克电流探头 TCP303 150A电流探头的详细资料
深圳市金博宇电子有限公司是专业从事测试仪器仪表设备的代理经销售后服务集成商，并与国内外仪表生产厂商有着广泛的技术与销售合作.作为美国菲利尔FLIR、美国FLUKE、美国泰克、美国Keithley 、美国安捷伦Agilent、台湾皇晶ACUTE、英国PEM、普源精电、青岛青智、费思泰克等诸多国内外代理与经销：主要销售的测试仪器仪表有: 示波器、信号源、万用表、热像仪、电流电压探头、电子负载、电源、频谱、等测试仪器。

服务热线： 服务 网站：www.jboyu.com


  • AC/DC Measurement Capabilities

  • DC – 100 MHz, Current Probe Amplifier (TCPA300) uses:

    • DC – 100 MHz, 30 A DC (TCP312)

    • DC – 50 MHz, 50 A DC (TCP305)

    • DC – 15 MHz, 150 A DC (TCP303)



  • DC – 50 MHz, Current Probe Amplifier (TCPA400) Uses:

    • DC – 2 MHz, 750*1 A DC (TCP404XL) (500 A DC Continuous)



  • Automatic Scaling and Units*2 – Oscilloscope On-screen Readout of Magnitude and Amps reduces Measurement Errors with No More Hand Calculations

  • AC/DC Input Coupling

  • Low Insertion Impedance reduces Device Under Test Loading

  • Split-core Construction allows Easy Circuit Connection

  • Status Indicators provide Visual Operating Status and Notification of Potential Error Conditions – Degauss, Probe Open, Overload, Not Terminated into 50 ?, Noncompatible Probe Type

  • Lower DC Drift and Noise allows Improved Low-level Current Measurements

  • Certified for use in U.S., Canada, and Europe. Complies with applicable IEC Standards.


Applications



  • Development and Analysis Solutions for Designers, Installers, and Service Personnel in Telecomm, Data Comm, Computer, and Semiconductor Power Electronics Environments for:

    • Power Supplies (Switching and Linear)

    • Semiconductor Devices (SCRs, IGBTs, MOSFETs, CMOS, BJTs)

    • Power Inverters/Converters

    • Electronic Ballasts

    • Industrial/Consumer Electronics

    • Mobile Communications (Phone, Satellite, Relay Stations)

    • Motor Drives

    • Transportation Systems (Electronic Vehicles, Electric Trains, Locomotives, Avionics)




Increased Performance and Simplicity


The TCP300 and TCP400 Series AC/DC current measurement family is a highly advanced current measurement system for today's current measurement needs. When connected to Tektronix oscilloscopes with TEKPROBE Level II, TekConnect (w/ TCA-BNC), or TekVPI (w/ TPA-BNC) interfaces, current measurements and calculations are simple and easy.


*1 Derated with duty cycle.


*2 Requires a TDS TEKPROBE oscilloscope or a TekConnect oscilloscope with TCA-BNC.


Meets Today's AC/DC Current Measurement Applications

The TCPA300 amplifier, when used with TCP312, TCP305, or TCP303 probes, provides a wide range of current measurement capability and spans the gap between low-level milliamp measurements to very high current levels. These three probes provide current measurement capabilities of 30 A, 50 A, and 150 A DC continuous. For even higher current levels, the TCPA400 amplifier with the TCP404XL current probe measures 500 A DC continuous and 750 A DC continuous, derated with duty cycle.


Higher frequency performance is available with the TCP312 w/TCPA300 providing ≥100 MHz bandwidth and a maximum current of 30 A DC.


Measurement Errors and Manual Calculations are Now a Thing of the Past

With this new series of current measurement tools, automatic control and on-screen scaling and units is provided for users of Tektronix TDS3000, TDS500, TDS600, TDS700, TDS5000, TDS6000, and TDS7000B Series oscilloscope systems (the DPO3000, DPO4000, and DPO7000 Series oscilloscopes, the TPA-BNC adapter is required).


The TCP300/TCP400 current measurement systems seamlessly integrate with your TDS Series oscilloscope.


Even non-TEKPROBE systems can use the TCPA300/400 Series to make proper current measurements by simply multiplying the measured output voltage on the oscilloscope by the TCPA300/400 Series range setting
