安诺尼 HyperLOG6080 对数周期天线(680MHz-8GHz)

一、简介：
With their log-periodic measurement antennas from the HyperLOG  60xxx series, Aaronia finally offers a very cost-effective alternative, which at the same time meets the highest expectations. In conjunction with the HyperLOG antennas, every regular spectrum analyser becomes a fully professional directional RF measurement device within a few moments. Thus, a perfect "dream team" for EMC measurement in the laboratory or for outdoor use is at your disposal.
Due to their small weight ａnd the multi-functional handle, these antennas are the optimal supplement for protable EMC measurement devices for locating ａnd evaluating any kind of signal source.

二、Highlights:
1、Optimal for usage with spectrum analysers for EMC measurement
2、Top-quality high-tech TEFLON antenna support
3、Excellent forward/backward ratio
4、Freely alignable polarisation
5、Excellent symmetry of radiation patterns
6、Integrated 1/4" tripod socket
7、Suitable for mobile use
8、Made in Germany

三、References / examples of proof:
1.BMW, München, Germany
2.Hewlett Packard, Dornach, Germany
3.Audi AG, Ingolstadt, German
4.DLR, Köln, Germany
5.University of Florida, USA
6.IBM, Stuttgart, Germany

四、规格参数
名      称：对数周期天线
型      号：HyperLOG6080
频率范围：680MHz-8GHz
校准点：733（10MHz步进）
输入功率：100 W CW(400MHz)
增益：5dBi（典型值）
驻波比：< 1：2.5
回波损耗：优于-10dB
天线系数：22-44dB/m
标准阻抗：50欧姆
射频连接：SMA
三脚架：1/4＇＇
重量：250g
尺寸（L/W/D）：340x200x25 mm
质保：2年
