供应福禄克绝压模块700PA5 绝压模块_详细资料

产品信息

供应福禄克绝压模块700PA5 绝压模块九九仪器仪表有限公司麻芸Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
Rugged urethane molded case protects the module from rough handling and harsh conditions
Features internal temperature compensation from 0o C to 50o C for full-accura

绝压模块700PA5 绝压模块

概述：Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
Rugged urethane molded case protects the module from rough handling ａnd harsh conditions
Features internal temperature compensation from 0º C to 50º C for full-accuracy performance
Includes NIST-traceable calibration certificate
Module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, ａnd a precision pressure source
One year warranty

技术指标：

Specifications

Range

30 psi / 207 kPa

Resolution

0.001 / 0.01

Reference Uncertainty （23 ± 3° C）

0.050%

Total¹ Uncertainty 1 year

0.070

High Side Media²

316 SS

Low Side Media²

N/A

Note

1）

Total uncertainty, one year for temperature range 0° C + 50° C.

Total uncertainty, 1.0% of full span for temperature range - 10° C to 0° C.

Compensated temperature range is 15° C to 35° C.

2）

"Dry" indicates dry air or non-corrosive gas as compatible media.

"316 SS" indicates media compatible with Type 316 Stainless Steel.

"C276" indicates media compatible with Hastelloy C276.

型号名称

描述

700PA5

压力模块
