供应福禄克700P02 差压模块

产品信息
供应福禄克700P02 差压模块九九仪器仪表有限公司麻芸Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
Rugged urethane molded case protects the module from rough handling and harsh conditions
Features internal temperature compensation from 0o C to 50o C for full-accuracy p

 700P02 差压模块

  • 概述：Display pressure readings in any of 10 different pressure units you specify in the calibrator setup

  • Rugged urethane molded case protects the module from rough handling ａnd harsh conditions

  • Features internal temperature compensation from 0º C to 50º C for full-accuracy performance

  • Includes NIST-traceable calibration certificate

  • Module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, ａnd a precision pressure source

  • One year warranty

技术指导：

Specifications

Range



 1 psi / 6900 Pa

Resolution



 0.0001 / 0.7

Reference Uncertainty （23 ± 3° C）



 0.150%

Total¹ Uncertainty 1 year



 0.300

High Side Media²



 Dry

Low Side Media²



 Dry

Note

1）

 Total uncertainty, one year for temperature range 0° C + 50° C.



 Total uncertainty, 1.0% of full span for temperature range - 10° C to 0° C.



 Compensated temperature range is 15° C to 35° C.

2）

 "Dry" indicates dry air or non-corrosive gas as compatible media.



 "316 SS" indicates media compatible with Type 316 Stainless Steel.



 "C276" indicates media compatible with Hastelloy C276.

型号名称

描述

700P02

差压模块 1 psi （70 mbar）

信息声明：本产品供应信息由仪器网为您整合，供应商为（深圳市九九仪器仪表有限公司），内容包括 （供应福禄克700P02 差压模块）的品牌、型号、技术参数、详细介绍等；如果您想了解更多关于 （供应福禄克700P02 差压模块）的信息，请直接联系供应商，给供应商留言！
