universal testing machine

品Pai：	JINSHI	型号：	WEW-1000B	类型：	液压式万能试验机
测量范围：	0-1000（kN）	精度：	1 CLASS	Z大负荷：	1000（kN）
拉伸空间：	700（mm）

Applications & Feature:This serial goods are mainly used for the mechanics property test such as the tensile, cutting, bending, compression etc. to various metal and nonmetallic materials. WEW serial testers have been developed according to GB228-2002 "Metal Tensile Test Method" with the adoption of the manual and hydraulic control micro-computer display and electronic measurement. It can automatically process the data and print the test report in accordance with the national standards. WEW serial goods use the micro-computer automatic data collection and processing, synchronous screen display of the test data and curves. It has the functions such as storing in the magnetic disk the test results, printing the test results and curves, processing the batch test result report, managing the database and so on. It also has the network interface. It can automatically seek the multiple technical parameters such as elastic module E ,upper yield strength Reh, lower yield strength REL,stipulated non-proportional elongation intensity Rr,tensile strength Rm,stipulated total elongation intensity Rt,yield point percentaege elongation etc.The serial goods have the features sush as the high precision,advantageous performance,high reliability,convenient operation etc. It completely conforms with GB/T3159-2008 and ISO. , ASTM requirements.主要技术参数Main technical parameters

Model & specification	WEW-100B	WEW-300B	WEW-600B	WEW-1000B	WEW-2000B
Max. test force (kN)	100	300	600	1000	2000
Measuring range (kN)	2%-FS Can improve range to 0.4%- FS
Relative error toforce value (%)	≤±1	≤±1	≤±1	≤±1	≤±1
Distance between compression surfaces (mm)	0-540	0-540	0-660	0-660	0-1000
Max. distance between tensile jaws (mm)	0-590	0-590	0-700	0-700	0-1000
Bending test pressed rolling distance (mm)	100-500	100-500	30-600	60-700	60-750
Clip diameter of round sample (mm)	Φ6-Φ20	Φ10-Φ32	Φ13-Φ40	Φ20-Φ60	Φ20-Φ70
Clip thickness of flat sample (mm)	0-15	0-15	0-30	0-40	0-40
Width of flat plate specimen (mm)	≤60	≤60	≤70	≤80	≤110
Size of shearing specimen (mm)	0-Φ10	0-Φ10	0-Φ20	0-Φ30	0-Φ30
Effective distance between the pillars (mm)	500	500	565	650	700
Piston stroke (mm)	150	150	200	200	250
Motor power (kW)	1.2	1.5	2.2	2.5	3.0
Main frame outline dimension (mm)	805×520×1850	805×520×1850	890×600×2210	1010×700×2400	1100×760×2700
Oil source control cabinet outline dimension (mm)	580×480×1000	580×480×1000	580×480×1000	580×480×1000	580×480×1000
Weight (about) (kg)	1500	1800	2600	3500	4500
