试验机，本公司生产优质产品，欢迎来电详谈！瑞航PaiRH-01F型Z字书写机简介瑞航Pai《RH-01F型Z字书写机》可适用于国外相关的检测标准，产品远销欧美等国家，国内知名企业及检测机构均有使用。具有操作简单、划线长度准确、自动化程度高等特点。RH-01F型可用于记号笔、荧光笔、白板笔和水彩笔等非滚珠类纤维笔的各种书写指标的检测。划线笔迹为“Z”字，因此线迹不会重叠、宽窄不一，使出墨量的测量、线迹尺寸的辨别和墨水颜色有检测非常容易和准确。是笔厂、笔芯厂、墨水厂不可缺少的检测设备。主要技术参数及特点：每次Z大检测笔芯支数：RH-01F 5支笔芯直线往复运动：行程100mm书写速度：10dm/min－120dm/min（连续可调）书写间距：1mm－4mm（连续可调）书写角度：50°－90°（连续可调，书写过程中可随时改变角度）划线距离可预设并实时显示划线距离，达到设定值后可自动停机。具有自动收纸功能，无需专人值守。采用自动起落笔方式，易于间歇书写。自动化的单键操作方式，划线自动完成。Brief Introduction to Ruihang RH-01 Writer Testing InstrumentHaving assimilated and summarized worldwide advanced technologies, Ruihang “RH-01 Writer Testing Instrument” is the most newly designed and produced pen core testing instrument. It has such features as simple operation, accurate testing length, high reliability, long service life, high automatization and so on.
Main Technical Parameters and Features Max number of pen cores that can be tested at a time：RH-01C 10 pieces RH-01D 5 piecesSelf-rotate speed of pen cores：1r/minRevolution motion of pen core：100mm/roundTesting speed：10dm/min—120dm/min（continuously adjustable）Testing space：1mm—4mm（continuously adjustable）Testing angle：50°—90°（continuously adjustable，can be changed any time in the course of testing） |
RH-01C is applicable to test pen cores of ball pens and gel pens. RH-01D is applicable to test marker and white board marker. This writer testing instrument is applicable to test such writing performance index as writing quality, ink flow rate, writing length, wear of pen head as well as the writing quality of ink. It is an indispensable testing instrument for pen factories, pen core factories and ink factories.Tianjin Ruihang Motor Co., Ltdaddress：No. 186, Santan Road, Nankai district, TianjinPostal code：300192Tel： Fax：27420488Please contact：Liang Rui Cell phone：
