测试频率

12Hz ~ 200kHz (504 steps) for LCR-821
12Hz ~ 100kHz(503 steps) for LCR-819/829
12Hz ~ 10kHz(489 steps) for LCR-817/827
100Hz ~2kHz (245 steps) for LCR-816/826

基本准确度(*)

0.05% for basic accuracy for LCR-821/819/817
0.1% for basic accuracy for LCR-829/827/826/816

测试速度

68ms for LCR-821/819/817/816, 34ms for LCR-829/827/826

测试电压

5mV ~ 1.275Vrms ( 5mV/step ) for LCR-821/819/829/817/827
0.1V ~ 1.275Vrms ( 5mV/step )for LCR-816/826

直流偏压

内部

2V

外部

0 ~ 35V for LCR-821; 0 ~ 30V for LCR-819/829/817/827/816/826

显示范围(**)

电阻(R)

0.00001Ω ~ 99999kΩ

电容(C)

0.00001pF ~ 99999uF

电感(L)

0.00001mH ~ 99999H

品质因子(Q)

0.0001 ~ 9999

损失因子(D)

0.0001 ~ 9999

阻抗(|Z|)

0.00001Ω ~ 99999kΩ for LCR-821

相位(θ)

-180.00° ~ 180.00° for LCR-821

量测模式

R/Q, C/D, C/R, L/Q, Z/θ, L/R
Z/θ, L/R for LCR-821 only

等效电路

串联or并联(可切换)

内存

100 memory blocks total

平均

1 to 255 times

测试速度模式

SLOW, MEDIUM and FAST

显示模式

Value,△,△%

显示屏

240 x 128 dot matrix C.C.F.L back light LCD

接口(标准)

Standard Interface : RS-232C for LCR-821
Standard Interface : Handler Interface for LCR-829/827/826
Optional : RS-232C Interface for LCR-819/817/816
(Including LCR-Viewer Software)

使用电源

输入范围

100V - 240V, 47-63Hz/400Hz

尺寸及重量

330(宽) x 149(高) x 437(长)mm
