产品库

美国台式水浴锅振荡器

产品信息
美国台式水浴锅摇床,特征变量的速度旋转拨号控制,直流电机,和一个LED数码管显示温度。一个集成转速监视器和显示速度转来保证准确的设置,和定时器允许连续运行时间从60分钟或1–摇。围绕并保护聚酯控制面板
产品货号:47742-916 产地:美国 品牌商标:VWR 数量:大量 保修期:两年
美国VWR水浴锅摇床Barnstead/Lab-Line MaxQ* 7000 Benchtop Water Bath Shakers, Thermo Scientific

台式水浴摇床是理想的,需要一个温度控制浴结合轨道振动的应用。振动筛的特点一个易于访问的排水系统,快速断开,位于箱体前在排水和消毒系统方便。在室双挡板减少飞溅和湍流即使在高速度。理想的溶解度的研究,提取程序,细胞培养,一般混合,杂交,细菌悬液,诊断测试,染色,脱色,洗涤程序。三偏心驱动可连续24小时运行,处理更重的负荷,并提供完整的或不平衡负载平滑均匀搅拌即使在高速度。监控和PID温度控制器,控制槽液温度。视觉,用户可调超温安全信号独立温控器提供了额外的备份,通过控制热如果主控制器失败。振动特征的粉末涂层,冷轧钢外,和一个无缝不锈钢内圆角。一个强大的,ABS外壳包围和保护聚酯控制面板Ideal for applications that require a controlled temperature bath combined with orbital shaking motion. Shakers feature an easy access drain system with quick disconnect, located in the front of the cabinet for convenience in draining and disinfecting the system. Twin baffles in the chamber minimize splashing and turbulence even at high speeds. Ideal for solubility studies, extraction procedures, cell cultures, general mixing, hybridization, bacterial suspensions, diagnostic tests, staining, destaining, and washing procedures. Triple eccentric drive enables continuous 24-hour operation, handles heavier loads, and provides smooth uniform agitation of full or unbalanced loads even at high speeds. Monitor and control bath temperature with PID temperature controller. Visual, user-adjustable overtemperature safety signal with independent thermostat provides additional backup by controlling the heat if the main controller fails. Shakers feature a powder-coated, cold-rolled steel exterior, and a seamless stainless steel interior with rounded corners. A strong, ABS housing surrounds and protects the polyester control panel.


Analog units feature variable speed controlled by a rotary dial, a DC motor, and an LED digital display of temperature. An integrated tachometer monitors and displays speed in rpm to guarantee accurate setting, and the timer allows for continuous operation or timed shaking from 1–60 minutes.
Digital units feature variable speed control, adjustable with up/down arrows, and a solid-state, brushless DC motor. Separate LED displays for temperature, speed, and operating time. Speed is adjustable in 1rpm increments. Shaker shutdown and audible and visual signals indicate speed deviations ±10% of setpoint, and temperature deviations of ±1°C of setpoint. Timer allows for continuous operation or timed shaking from 0.1–999 minutes, or from 0.1–999 hours. Soft-start feature helps prevent sudden starts and stops to eliminate splashing of vessel contents and wetting of flask closure. Setpoint retention retains parameters during power failure and restarts unit automatically after power is restored. RS-232 interface allows remote monitoring of temperature, speed, and time. For monitoring temperature, the built-in recorder jack allows output to a chart recorder for a permanent record.
The cooling coil accessory allows the bath to reach near-ambient temperature and below. Gable covers prevent heat loss and minimize evaporation. The stainless steel gable cover is for use in operations where temperatures reach up to 90°C (194°F). The Plexiglas® gable cover is for use in operations where temperatures reach up to 65°C (149°F). The four auxiliary platform suspension arms allow for rapid platform changing. The movable dolly allows for under lab bench operation.
Ordering Information: Five-year manufacturer’s warranty on parts; one-year manufacturer's warranty on labor; and lifetime manufacturer’s warranty on drive mechanism. For universal platforms, see the 57018-990 series. For clamps, see the 97007-248 series. For tube racks, see the 80080-554 series.
UL and C-UL listed. CE marked.
Exterior Dimensions 54.6W x 63.5L x 45.7H cm (211/2 x 25 x 18")
Interior Dimensions 35.6W x 40.6L x 20.3H cm (14 x 16 x 8")
Load Capacity 15.9 kg (35 lbs.)
Temperature Accuracy ±0.2°C at 37°C in flask
Temperature Range 5° above ambient to 65°C (149°F)

Description
Electrical
Orbit
Speed Range
Temperature Range
Shipping Weight
Supplier No.
VWR Catalog Number
Analog Shaker
240V, 50/60Hz
1.3 cm (1/2")
40–400 rpm
5° above ambient to 65°C (149°F)
48.5 kg (107 lbs.)
SHKA7000-1CE
47742-916
Digital Shaker
240V, 50/60Hz
1.3 cm (1/2")
15–500 rpm
5° above ambient to 65°C (149°F)
48.5 kg (107 lbs.)
SHKE7000-1CE
47742-920


信息声明:本产品供应信息由仪器网为您整合,供应商为(北京东方大林科技有限公司),内容包括 (美国台式水浴锅振荡器)的品牌、型号、技术参数、详细介绍等;如果您想了解更多关于 (美国台式水浴锅振荡器)的信息,请直接联系供应商,给供应商留言!
