贴片XBee-PROTM ZigBee OEM 模块

Platform

XBee® ZB

XBee-PRO® ZB

性能

RF 数据率

250 Kbps

室内/市区距离

200 ft (60 m)

300 ft (90 m)

室外/RF视距范围

4000 ft (1200 m)

2 miles (3200 m)

发射功能

3.1 mW (5 dBm) / 6.3 mW(+8 dBm) boost mode

63 mW (+18 dBm)

接收灵敏度 (1% PER)

-102 dBm

-101 dBm

特色

功耗可调

Yes

串行数据接口

UART, SPI

配置方式

API or AT commands

频段

ISM 2.4 GHz

Interference Immunity

DSSS (Direct Sequence Spread Spectrum)

Serial Data Rate

Up to 1 Mbps

ADC Inputs

(4) 12-bit ADC inputs

Digital I/O

Up to 16 configurable GPIO pins depending on module configuration

Antenna Options

PCB (embeded), U.FL and RF PAD

Programmability

Yes, 32k running at 20 MHz (available in programmable variant)

Dimensions (L x W)

0.87 in x 1.33 in (2.20 cm x 3.40 cm)

Networking & Security

Encryption

128-bit AES

Reliable Packet Delivery

Retries/Acknowledgments

Addressing Options

PAN ID and addresses, cluster IDs and endpoints (optional)

Network Channels

11 - 26

Network Topologies

Mesh

Power Requirements

Power Input

2.1 to 3.6V

2.7 to 3.6V

Power Consumption

(approx) 150 mW at Pout = +8 dBm and 3.3V

330 mW at Pout = +18 dBm when VCC = 3.3V

Transmit Current

45 mA @ +8 dBm

100 mA @ +18 dBm

Receive Current

30 mA in boost mode

Power-Down Current

> 1 uA @ 25° C

< 1 uA @ 25° C

Sleep Current

0.3 uA - 0.4 uA

Regulatory Approvals

FCC (USA)

Yes

IC (Canada)

Yes

ETSI (Europe)

Yes

No

C-TICK (Australia)

Yes

TELEC (Japan)

Yes
