| 通径DN
(m) | 型 号 | 测量范围 | 椎管长度(m) | 精度等级 | 允许被测液体状态 |
| 水20℃ | 空 气
20℃，10132SPa | LZB/LZJ | LZB-()F | 温度(℃) | 压力
(MPa) |
| 2 | LZB-2 | 0.4~4ml/min
0.6~6ml/min
1.0~10ml/min
1.6~16ml/min | 6~60ml/min
10~100ml/min
16~160ml/min
25~250ml/min | 160 | 1.5:2.5 | 2.5:4 | -20~+120 | ≤0.4 |
| 3 | LZB-3 | 2.5~25ml/min
4~40ml/min
6~60ml/min
10~100ml/min | 40~400ml/min
60~600ml/min
100~1000ml/min
160~1600ml/min |
| 4 | LZB-4
LZB-4F | (1~10)L/h
(1.6~16)L/h
(2.5~25)L/h | (16~160)L/h
(25~250)L/h
(40~400)L/h |
| 6 | LZB-6
LZJ-6
LZJ-6F | (2.5~25)L/h
(4~40)L/h
(6~60)L/h | (40~400)L/h
(60~600)L/h
(100~1000)L/h |
| 10 | LZB-10
LZJ-10
LZJ-10F | (6~60)L/h
(10~100)L/h
(16~160)L/h | (100~1000)L/h
(160~1600)L/h
(250~2500)L/h | 2.5 | ≤0.6 |
| 15 | LZB-15
LZJ-15F | (16~160)L/h
(25~250)L/h
(40~400)L/h | (0.25~2.5)m³/h
(0.4~4)m³/h
(0.6~6)m³/h | 350 |
| 25 | LZB-25
LZJ-25F | (40~400)L/h
(60~600)L/h
(100~1000)L/h | (1~10)m³/h
(1.6~16)m³/h
(2.5~25)m³/h |
| 40 | LZB-40
LZJ-40F | (160~1600)L/h
(250~2500)L/h | (4~40)m³/h
(6~60)m³/h | 430 |
| 50 | LZB-50
LZJ-50F | (0.4~4)m³/h
(0.6~6)m³/h | (10~100)m³/h
(16~160)m³/h | 450 |
| 80 | LZB-80
LZB-80F | (1~10)m³/h
(1.6~16)m³/h | (50~250)m³/h
80~400)m³/h | 500 | ≤0.4 |
| 100 | LZB-100
LZB-100F | (5~25)m³/h
(8~40)m³/h | (120~600)m³/h
(200~1000)m³/h |
