pBARGPE1-Hygro-EGFP Search name
pBARGPE1-Hygro-EGFP,Plasmid pBARGPE1-Hygro-EGFP,pBARGPE1-Hygro-EGFP vector
pBARGPE1-Hygro-EGFP Information
Promoter: gpdA, TrpC
Replicon: pUC ori
Terminator: trpC
Plasmid classification: other host shuttle vectors; filamentous fungi expressing plasmids.
Plasmid size: 6700bp
Plasmid label: enhanced green fluorescent protein EGFP
Prokaryotic resistance: ampicillin Ampicillin
Screening markers: hygromycin Hygromycin
Cloned strain: DH5 alpha
Culture conditions: 37 centigrade, aerobic, LB
Expression host: filamentous fungi
5'sequencing primers: Based on full sequence design
3'sequencing primers: Based on full sequence design
Note: the expression of EGFP fusion protein
Use:Filamentous fungal plasmid
pBARGPE1-Hygro-EGFP Description
PBARGPE1-Hygro-EGFP is a filamentous fungus - Escherichia coli shuttle expression vector. The expression of exogenous target gene can be activated by gpdA promoter, and it can be transformed into filamentous fungi to be screened by hygromycin Hygromycin.
pBARGPE1-Hygro-EGFP Sequence
LOCUS Exported 6700 bp ds-DNA circular SYN 30-AUG-2016
DEFINITION synthetic circular DNA.
ACCESSION .
VERSION .
KEYWORDS pBARGPE1-Hygro-EGFP
SOURCE synthetic DNA construct
ORGANISM synthetic DNA construct
REFERENCE 1 (bases 1 to 6700)
AUTHORS .
TITLE Direct Submission
JOURNAL Exported Tuesday, August 30, 2016 from SnapGene Viewer 3.1.4
FEATURES Location/Qualifiers
source 1..6700
/organism="synthetic DNA construct"
/mol_type="other DNA"
primer_bind 18..34
/note="KS primer"
/note="common sequencing primer, one of multiple similar
variants"
CDS complement(55..774)
/codon_start=1
/product="enhanced GFP"
/note="EGFP"
/note="mammalian codon-optimized"
/translation="MVSKGEELFTGVVPILVELDGDVNGHKFSVSGEGEGDATYGKLTL
KFICTTGKLPVPWPTLVTTLTYGVQCFSRYPDHMKQHDFFKSAMPEGYVQERTIFFKDD
GNYKTRAEVKFEGDTLVNRIELKGIDFKEDGNILGHKLEYNYNSHNVYIMADKQKNGIK
VNFKIRHNIEDGSVQLADHYQQNTPIGDGPVLLPDNHYLSTQSALSKDPNEKRDHMVLL
EFVTAAGITLGMDELYK"
primer_bind 789..805
/note="KS primer"
/note="common sequencing primer, one of multiple similar
variants"
misc_feature complement(855..1539)
/note="gpdA Promotor"
misc_feature 1754..1894
/note="bom"
/note="basis of mobility region from pBR322"
rep_origin complement(2080..2668)
/direction=LEFT
/note="ori"
/note="high-copy-number ColE1/pMB1/pBR322/pUC origin of
replication"
CDS complement(2839..3699)
/codon_start=1
/gene="bla"
/product="beta-lactamase"
/note="AmpR"
/note="confers resistance to ampicillin, carbenicillin, and
related antibiotics"
/translation="MSIQHFRVALIPFFAAFCLPVFAHPETLVKVKDAEDQLGARVGYI
ELDLNSGKILESFRPEERFPMMSTFKVLLCGAVLSRIDAGQEQLGRRIHYSQNDLVEYS
PVTEKHLTDGMTVRELCSAAITMSDNTAANLLLTTIGGPKELTAFLHNMGDHVTRLDRW
EPELNEAIPNDERDTTMPVAMATTLRKLLTGELLTLASRQQLIDWMEADKVAGPLLRSA
LPAGWFIADKSGAGERGSRGIIAALGPDGKPSRIVVIYTTGSQATMDERNRQIAEIGAS
LIKHW"
promoter complement(3700..3804)
/gene="bla"
/note="AmpR promoter"
promoter 3910..4011
/gene="S. cerevisiae TRP1"
/note="TRP1 promoter"
misc_feature 4102..4487
/note="TrpC Promotor"
CDS 4488..5513
/codon_start=1
/gene="aph(4)-Ia"
/product="aminoglycoside phosphotransferase from E. coli"
/note="HygR"
/note="confers resistance to hygromycin"
/translation="MKKPELTATSVEKFLIEKFDSVSDLMQLSEGEESRAFSFDVGGRG
YVLRVNSCADGFYKDRYVYRHFASAALPIPEVLDIGEFSESLTYCISRRAQGVTLQDLP
ETELPAVLQPVAEAMDAIAAADLSQTSGFGPFGPQGIGQYTTWRDFICAIADPHVYHWQ
TVMDDTVSASVAQALDELMLWAEDCPEVRHLVHADFGSNNVLTDNGRITAVIDWSEAMF
GDSQYEVANIFFWRPWLACMEQQTRYFERRHPELAGSPRLRAYMLRIGLDQLYQSLVDG
NFDDAAWAQGRCDAIVRSGAGTVGRTQIARRSAAVWTDGCVEVLADSGNRRPSTRPRAK
K"
protein_bind 5905..5938
/bound_moiety="Cre recombinase"
/note="loxP"
/note="Cre-mediated recombination occurs in the 8-bp core
sequence (GCATACAT)."
protein_bind 6016..6049
/bound_moiety="Cre recombinase"
/note="loxP"
/note="Cre-mediated recombination occurs in the 8-bp core
sequence (GCATACAT)."
misc_feature 6443..6673
/note="trpC terminator"
ORIGIN
1 ggtaccgggc cccccctcga ggtcgacggt atcgataagc ttgatatcga attcttactt
61 gtacagctcg tccatgccga gagtgatccc ggcggcggtc acgaactcca gcaggaccat
121 gtgatcgcgc ttctcgttgg ggtctttgct cagggcggac tgggtgctca ggtagtggtt
181 gtcgggcagc agcacggggc cgtcgccgat gggggtgttc tgctggtagt ggtcggcgag
241 ctgcacgctg ccgtcctcga tgttgtggcg gatcttgaag ttcaccttga tgccgttctt
301 ctgcttgtcg gccatgatat agacgttgtg gctgttgtag ttgtactcca gcttgtgccc
361 caggatgttg ccgtcctcct tgaagtcgat gcccttcagc tcgatgcggt tcaccagggt
421 gtcgccctcg aacttcacct cggcgcgggt cttgtagttg ccgtcgtcct tgaagaagat
481 ggtgcgctcc tggacgtagc cttcgggcat ggcggacttg aagaagtcgt gctgcttcat
541 gtggtcgggg tagcggctga agcactgcac gccgtaggtc agggtggtca cgagggtggg
601 ccagggcacg ggcagcttgc cggtggtgca gatgaacttc agggtcagct tgccgtaggt
661 ggcatcgccc tcgccctcgc cggacacgct gaacttgtgg ccgtttacgt cgccgtccag
721 ctcgaccagg atgggcacca ccccggtgaa cagctcctcg cccttgctca ccatggatcc
