Electro chemical Kinetics / SPR cell 电化学动力学/SPR单元

ApplicationThe electro chemical Kinetics / SPR cell is based on Nanofilm’s Kinetics / SPR cell with additional electrodes. Therefore, electrochemical and ellipsometrical sample evaluation can be done in parallel.The sample should be transparent and a conductive surface is required. By ellipsometrical examination an adsorption of organic material (e.g. proteins) on the sample’s surface can be-recorded.The materials of this cell are biocompatible and suited for water based liquids like salt solutionsSpecificationsCell• sample dimensions: 15 x 22 x 1...10 mm³ to 26 x 76 x 1...10 mm³• for OptiSlides or standard microscope slides• volume: 0.1 ml + tubing (>0.1 ml minimum)• observable area: 4 x 8 mm• field of view: 2 x 3 mm (2x objective)• material: PEEK® (cell and tubing) and Viton® for O-Rings• exchange of the internal volume within 20 to 30 s (at a flow rate of 0.5 to 1.0 ml/min).• standard HPLC fittings (1/4”-28)• o-rings, screws, suitcase, manual• diameter of the electrodes: 2 mmTemperature sensor• PT100 temperature sensor close to the measuring chamber directly under the sample• external temperature display including data-transfer to the EP³-View-software (optional)Peltier temperature device (optional)• peltier based temperature device for temperature adjustment from 5°C to 85°C.the temperature sensor and display are included in this package.(note: thermal noise might limit your sensitivity)
