筒状加热器（cartridge heaters）
- 品牌：美国/Cryocon
- 型号：Cartridge
- 产地：进口
- 供应商：北京飞斯科科技有限公司
- 标签：筒状加热器（cartridge heaters）, 货号：, 美国/Cryocon, Cartridge, 北京飞斯科科技有限公司,筒状加热器（cartridge heaters）报价/价格,销售，使用，原理，操作，说明书，资料下载，促销，技术参数，维修，保修，售后服务，代理商，经销商，技术支持，进口/国产，用途
产品库
|
Cartridge Heaters |
50 and 25 Ohm cartridge heaters
|
|
Power Output
|
50Watts when used with a Cryo-con controller in the 50 Watt mode: 50V @ 1A
25Watts when used with a Cryo-con controller in the 25 Watt mode: 25V @ 1A |
|
Resistance
|
50Ohms ± 10%
25Ohms ± 10%
|
|
Size
|
Length: 1.125” (29mm) Width: 0.245” (6.25mm)
|
|
Construction
|
Nickel-chromium resistance element. Magnesium oxide insulation. Silicon Free. Incoloy™ shell. Non-magnetic.
|
|
Leads
|
Length: 2” (51mm), Diameter: 0.025” (0.63mm) 22AWG, Material: Solid Nickel
|
|
Ratings
|
Maximum operating temperature: 1,000K Maximum Current: 4.4A
|
|
Agency Approvals
|
UL component rated to 240V~ (ac) CSA component rated to 240V~ (ac)
VDE component rated to 240V~(ac) |
|
Mounting
|
Recommended hole size: 0.250” (6.35mm) for compression fit.
Or, 0.261” (6.63mm) for mounting in Stycast™ Epoxy. |
