3492 3492多路转换器模块

3492多路转换器模块,是德3492

Keysight 3492用于34980A多功能开关/测量单元的Keysight 3492模块是一款配备了长久耐用型固态继电器的高速多路复用器。高速FET继电器可提供高达1000通道/秒的扫描速率。该模块适用于需要高速、长时间使用继电器的高容量自动测试应用。

主要特性与技术指标

3492多路转换器模块,是德3492

用于34980A多功能开关/测量单元的Keysight 3492模块是一款配备了长久耐用型固态继电器的高速多路复用器。高速FET继电器可提供高达1000通道/秒的扫描速率。该模块适用于需要高速、长时间使用继电器的高容量自动测试应用。

双线和4线通道既可在同一模块上混合配置，也可配置为单线多路复用器。标准的50针Dsub连接器可与标准电缆、端子块或大容量互连解决方案一起使用。

说明：40/80通道光隔离FET多路转换器

Z大电压：±80V

Z大电流：0.0

BW(MHz)：1MHz

扫描(ch/sec)：与工厂联系

热偏移：<3uV

注释：配置为1线、2线或4线

3492多路转换器模块,是德3492

选件与附件

3492-ABA	English printed manual included; full documentation on Product Reference CD ROM
34925T	Terminal Block for 3492 40/80-Channel FET Multiplexer
34925T-001	Terminal Block for 2-wire applications
34925T-002	Terminal Block for 1-wire applications
Y1131A	Verification and Diagnostic Tools for 34980A Mainframe and Plug-in Modules
Y1131A-001	One verification board that works with either the 34921A, 34923A, 3492 Multiplexer
Y1131A-002	One verification board that works with either the 34922A, 23924A Multiplexer
Y1131A-003	One verification board that works with either the 34931A, 34932A, 34933A Matrix
Y1131A-004	One verification board that works with the 34937A General Purpose Switch
Y1131A-005	One verification board that works with the 34938A General Purpose Switch
Y113	1.5 meter 50 pin Dsub, M/F Twisted Pair with Outer Shield Cable - 300V
Y1136A	3 meter 50 pin Dsub, M/F Twisted Pair with Outer Shield Cable - 300V
Y1139A	Solder cup connector kit with female 50-pin Dsub
