GW temperature sensor

品Pai	saierde	型号	GW
种类	温度	材料	金属
材料物理性质	介质	材料晶体结构	气液
制作工艺	温度-气体感温	输出信号	开关型
防护等级	II	线性度	5（%F.S.）
迟滞	2（%F.S.）	重复性	1（%F.S.）
灵敏度	0.5	漂移	1.0
分辨率	1.0

temperature sensorIt is a temperature sensing element that is used for room thermostat, and also can be widely used for other industries which need controlling constant temperature and connecting signal device actuated by temperature changed.Technical specifications1.Diaphragm : φ38mm or φ51mm , easy for installation, sensible and reliable2.Adjusting temperature range : 5-30℃3.Temperature differential : 1.5℃4.Ambient temperature: Max.60℃5.It can also be manufactured according to customers’sample or specific requirementJX Series Temperature Adjusting & Controlling ElementsIt comprises of 3 parts (adjusting part, temperature sensing part, snap-action switch ) and is used for room thermostat, it also can be used in other industries which need controlling constant temperature. When temperature increases or decreases ,temperature detecting/sensing element can expand or shrink axially ,and this can push or pull the spring of snap-action switch , so it can automatically control and maintain the ambient temperature at a set-point.The screw adjusting part is used to set required temperature. It can adjust the temperature between 5～30℃ for commercial air conditioners. For the other purposes, it can adjust the temperature between -15 and 40℃.Technical specification1.Adjusting temp. : 5～30℃2.Temp.tolerance : 1.5℃3.Ambient temperature : Max.+60℃4.Rated power supply: 220VAC±10% 50/60Hz, also applicable to 110V/24V5.Load current : ＜3A resistive load ; ＜16A resistive load6.Service life :Over 100,000 times
