南非CCG防爆非铠装格兰（CCG A2EX，Posi Grip，A2F cable gland）


	CCG Products are produced under the quality management system ISO9001-2000 standard underwritten by UL USA. CCG Products are internationally certified to British, CENELEC/ATEX, Chinese, South African IEC and Australian standards where applicable.




		A2EX EExde IIC Compression Gland for flexible cable For indoor / outdoor use and hazardous areas (A2 Type)

		Posi Grip EExe Compression Gland for flexible cable For use in highly corrosive and hazardous conditions

		A2EX FHC EExde IIC Compression Gland for flexible cable housed in conduit For use indoors and hazardous areas

		A2F EExde IIC Compression Gland for flexible cable For use indoors/outdoors and hazardous areas

		CCG BarrierTex^TM F, Barrier EEx d Cable Gland for elastometric cable For use in potentially explosive atmospheres

A2EX EExde IIC compression gland
for unarmoured cable

Features and Benefits
•For indoor/outdoor use and hazardous areas. (A2E Type)
•Fitted with two specially formulated elastomeric seals. Inner seal seals
on the cable sheath. Harder outer seal grips the cable, giving superior
cable retention and IP rating
•Manufactured from high quality brass and nickel plated.
•Supplied with a polypropylene sealing gasket.

Technical Data

*Type*	A2EX
*Gland Material*	Brass (Nickel Plated), stainless steel and aluminium*
*Seal Material*	Thermoplastic Elastomer (Silicone on request)
*Cable Type*	Unarmoured
*Sealing Area*	Outer sheath
*Optional Accessories*	Locknut, Shroud, Earth Tag, Adaptor / Reducer

Download Data Sheet

Download Assembly Instructions

Standards and Certifications

*Hazardous Area Classification*
SANS/SABS IEC, AS/NZS IEC, CNEx	Zone 1, 2, 21 and 22 Exde IIC and DIP
CENELEC / ATEX	Category 2, Category 3, EExde II 2 GD
*Compliance Code*	*Certification No.*
CENELEC / ATEX
EN50014:1997E	DEMKO 01 ATEX 130325X
EN50018:2000E	DEMKO 01 ATEX 130325X
EN50019:2000E	DEMKO 01 ATEX 130325X
EN50281-1-1:1999E	DEMKO 01 ATEX 130325X
SANS / SABS / IEC
SANS/SABS 1213		SABS S/W 444UX
SANS/SABS IEC 60079-0	2000	SABS S/W 444UX
SANS/SABS IEC 60079-1	2001	SABS S/W 444UX
SANS/SABS IEC 60079-7	2001	SABS S/W 444UX
SANS/SABS IEC 60529	1989	SABS S/W 444UX
SANS/SABS IEC 61241.1.1	1999	SABS S/W 444UX
AUSTRALIAN / NEW ZEALAND / IEC
AS/NZS IEC 60079-0	2000	AUS Ex 03.3844X-1
AS/NZS IEC 60079-1	2001	AUS Ex 03.3844X-1
AS/NZS IEC 60079-7	2001	AUS Ex 03.3844X-1
AS/NZS IEC 60529	1989	AUS Ex 03.3844X-1
AS/NZS IEC 61241.1.1	1999	AUS Ex 03.3844X-1
CHINESE
GB3638. 1-2000 part 1		CNEx09 0429U
GB3638. 2-2000 part 2		CNEx09 0429U
GB3638. 3-2000 part 3		CNEx09 0429U
GB12476. 1-2000		CNEx09 0429U

Ingress Protection

IP66/67/68

Operating Temperature

-30?C TO +130?C

	Download Certification AUS Ex 03.3844X
	Download Certification DEMKO 01 ATEX 130325X
	Download Certification CNEx09 0429U
	Download Permit No SANS/SABS 1213
	Download Certification SABS S/W444UX
	ABS 09-SG435709-PDA

Special Conditions for Safe Use - X
Glands must be used as part of a certified assembly in surface installations only
Not for use on Exd enclosures that are larger than 2000cm³ volume in group IIC gases in zone 1 areas

Posi Grip EExe compression gland
for unarmoured cable

Features and Benefits
•For use in highly corrosive and hazardous areas.
•All brass parts encapsulated in a non-corrosive body.
•Complete with a hard gripper seal, deluge proof O-ring and elastomeric
inner seal for complete ingress protection IP68.
•Supplied with a polypropylene gasket.

Technical Data

*Type*	POSIGRIP
*Gland Material*	Brass encapsulated in Glass Reinforced Polyester/PBT
*Seal Material*	Thermoplastic Elastomer (silicone on request)
*Cable Type*	Unarmoured
*Sealing Area*	Outer sheath
*Optional Accessories*	Locknut

Download Data Sheet

Download Assembly Instructions

Standards and Certifications

*Hazardous Area Classification*
IEC, SABS & AUS Ex, CNEx		Zone 1, 2, 21and 22 Exe IIC and DIP
CENELEC / ATEX		Category 2, Category 3, EExe II 2 GD

*Compliance Code*		*Certification No.*
CENELEC / ATEX
EN50014:1997E		DEMKO 01 ATEX 130325X
EN50019:2000E		DEMKO 01 ATEX 130325X
EN50281-1-1:1999E		DEMKO 01 ATEX 130325X
SANS / SABS / IEC
SANS/SABS 1213		SABS S/W 458U
SANS/SABS IEC 60079-0	2000	SABS S/W 458U
SANS/SABS IEC 60079-7	2001	SABS S/W 458U
SANS/SABS IEC 60529	1989	SABS S/W 458U
SANS/SABS IEC 61241.1.1	1999	SABS S/W 458U
AUSTRALIAN
AS 2380.6		AUS Ex 2404U
AS 1939		AUS Ex 2404U
NSW MDA		Exe 3171
CHINESE
GB3638. 1-2000		CNEx09 0429U
GB3638. 3-2000		CNEx09 0429U
GB12476.1-2000		CNEx09 0429U

Ingress Protection

IP66/67/68

Operating Temperature

-30?C to +130?C

	Download Certification AUS Ex 2404U
	Download Certification DEMKO 01 ATEX 130325X
	Download Certification CNEx09 0429U
	Download Permit No SANS/SABS 1213
	Download Certification SABS S/W458U
	ABS 09-SG435709-PDA

A2EX FHC EExde IIC compression gland
for unarmoured cable housed in conduit

Features and Benefits
•For indoor/outdoor use and hazardous areas. (A2E Type)
•For use with all types of unarmoured cable housed in rigid or flexible conduit.
•Fitted with two specially formulated elastomeric seals. Inner seal seals on
the cable sheath. Harder outer seal grips the cable, giving superior cable retention and
IP rating
•Fitted with a rotating female connection for connection to conduit.
•Manufactured from high quality brass and nickel plated and stainless steel.
•Supplied with a polypropylene sealing gasket.

Technical Data

*Type*	A2EX FHC
*Gland Material*	Brass (Nickel Plated), Stainless Steel
*Seal Material*	Thermoplastic Elastomer (Silicone on request)
*Cable Type*	Unarmoured in Conduit
*Sealing Area*	Inner sheath
*Optional Accessories and Tools*	Locknut, Shroud, Earth Tag, Adaptor / Reducer

Download Data Sheet

Download Assembly Instructions

Standards and Certifications

Hazardous Area Classification

SANS / SABS IEC	Zone 1, 2, 21and 22 Eexde IIC and DIP
CENELEC / ATEX	Category 2, Category 3, EExde II 2 GD
Compliance Code	Certification No.
CENELEC / ATEX
EN50014:1997E		DEMKO 01 ATEX 130325X
EN50018:2000E		DEMKO 01 ATEX 130325X
EN50019:2000E		DEMKO 01 ATEX 130325X
EN50281-1-1:1999E		DEMKO 01 ATEX 130325X
SANS / SABS / IEC
SANS/SABS 1213, SABS 1031		SABS S/W 443UX
SANS/SABS IEC 60079-0	2000	SABS S/W 443UX
SANS/SABS IEC 60079-1	2001	SABS S/W 443UX
SANS/SABS IEC 60079-7	2001	SABS S/W 443UX
SANS/SABS IEC 60529	1989	SABS S/W 443UX
SANS/SABS IEC 61241.1.1	2000	SABS S/W 443UX

Ingress Protection

IP66/67/68

Operating Temperature

-30?C TO +130?C

	Download Certification DEMKO 01 ATEX 130325X
	Download Permit No SANS/SABS 1213
	Download Certification SABS S/W443UX
	ABS 09-SG435709-PDA

Special Conditions for Safe Use - X
Glands must be used as part of a certified assembly in surface installations only.
Not for use on Exd enclosures that are larger than 2000cm³ volume in group IIC gases in zone 1 areas.

A2F EExde IIC compression gland
for FLEXIBLE CABLE

Features and Benefits
•For indoor/outdoor use and hazardous areas.
•Fitted with specially formulated elastomeric displacement seal, giving superior
cable retention, explosion protection and IP rating.
•Manufactured from high quality brass and nickel plated.
•Supplied with a polypropylene or neoprene sealing gasket.

Technical Data

*Type*	A2F
*Gland Material*	Brass (Nickel Plated)
*Seal Material*	Thermoplastic Elastomer (Silicone on request)
*Cable Type*	Unarmoured
*Sealing Area*	Outer sheath
*Optional Accessories and Tools*	Locknut, Shroud, Earth Tag, Adaptor / Reducer

Download Data Sheet

Download Assembly Instructions

Standards and Certifications

*Hazardous Area Classification*
CENELEC / ATEX	Category 2, Category 3, EExde II 2 GD

*Compliance Code*	*Certification No.*
CENELEC / ATEX
EN60079-0 2004		EPSILON 06 ATEX 2066X
EN60079-1 2004		EPSILON 06 ATEX 2066X

Ingress Protection

IP66/67/68

Operating Temperature

-30?C TO +130?C

Download Certification EPSILON 06 Atex 2066

Download SAEx S/08-517X CCG A2F/A2FX Cable Gland

Download CNEx 09.0717U

Special Conditions for Safe Use - X
Glands must be used as part of a certified assembly in surface installations only.
Not for use on Exd enclosures that are larger than 2000cm³ volume in group IIC gases in zone 1 areas.

BarrierTex F Barrier EExd Cable Gland
for elastometric, unarmoured cable

Features and Benefits
•Precision manufactured from high quality brass and nickel plated.
•Provides a barrier seal between the individual cores of the cable.
•Inspectable compound and flameproof chamber.
•Prevents explosive gasses propagating through a cable.
•Prevents gas and moisture migrating through a cable.

Technical Data

*Type*	BarrierTex F
*Gland Material*	Brass (Nickel Plated), Stainless Steel, Bronze
*Seal Material*	CCG FR308 or ST574 compound. Thermoplastic elastomer
*Cable Type*	Unarmoured cable
*Sealing Area*	Inner compound barrier and outer sheath

Download Data Sheet

Download Assembly Instructions

Standards and Certifications

*Hazardous Area Classification*
SANS/SABS IEC, AS/NZS IEC	Zone 1, 2, 21and 22, Exe, Exd I/IIC Ex tD A21
CENELEC / ATEX	Ex tD A21, Exd I/IIC, Exe I/IIC and DIP
*Compliance Code*	*Certification No.*
CENELEC / ATEX
EN60079-0 2006	SIRA 07 ATEX 1044X
EN60079-1 2004	SIRA 07 ATEX 1044X
EN60079-7 2003	SIRA 07 ATEX 1044X
EN61241-0 2006	SIRA 07 ATEX 1044X
SANS / SABS / IEC
SANS 808		SAEx MS/06-425X
SANS/SABS IEC 60079-0	2006	SAEx MS/06-425X
SANS/SABS IEC 60079-1	2004	SAEx MS/06-425X
SANS/SABS IEC 60079-7	2003	SAEx MS/06-425X
SANS/SABS IEC 61241-0	2005	SAEx MS/06-425X
SANS/SABS IEC 61241-1	2005	SAEx MS/06-425X
SANS/SABS IEC 60529	2001	SAEx MS/06-425X
AUSTRALIAN / NEW ZEALAND / IEC
IEC 60079-0	2004	ANZEx 07.4045X
IEC 60079-1	2003	ANZEx 07.4045X
IEC 60079-7	2001	ANZEx 07.4045X
IEC 61241-0	2004	ANZEx 07.4045X
IEC 61241.1	2004	ANZEx 07.4045X

Ingress Protection

IP66/67/68 (2m cont.)

Operating Temperature

-20?C TO +80?C

	Download Certification ITACS ANZEx 07.4045X
	Download Certification Sira 07ATEX1044X
	Download Certification SAEX MS06-425X (R6)
	ABS 09-SG435709-PDA
