Hawke153/RAC Cable GlandApplication

Outdoor or indoor use.
For use with single wire armour ‘W’, wire braid ‘X’, aluminium strip armour ‘Y’ and steel tape armour ‘Z’ elastomer and plastic insulated cables.

Ordering Format [ Gland Type / Size / Male Thread / Female Thread / Material / Options ]

Example without options: 153/RAC / C / M32 / Brass

Example with alternative seal option: 153/RAC / C / 1¼" NPT / Brass / S

Example with alternative clamping ring option: 153/RAC / C / 1¼" NPT / Brass / AR

Features

Provides armour clamping using one clamping arrangement for all armour/braid types.
Provides a seal on the cables inner sheath.
Provides a cable retention and low smoke and fume, zero halogen seal onto the cables outer sheath.

Materials & Finishes

The 153/RAC cable gland is manufactured in Brass (standard), Nickel Plated Brass, 316 Stainless Steel or Aluminium. Brass NPT entries are nickel plated as standard.

Technical Data

1. Construction and Test Standards:
   EN 62444, BS 6121 : Part 1 Type E1W, E1X, E1Y and E1Z.
2. Ingress Protection:
   IP66, IP67 and IP 68 (30 metres for 7 days) to IEC/EN 60529 and NEMA 4X.
3. Operating Temperature Range:
   -60°C to +80°C
4. Deluge Protection to:
   DTS01 (Deluge seal optional).
5. Assembly Instruction Sheet:
   AI 399.

CABLE GLAND SELECTION TABLE
Size Ref.	Entry Thread Size			Thread Length ‘H’	Cable Acceptance Details								‘G’ Compressed Length	Hexagon Dimensions
					Inner Sheath ‘A’				Outer Sheath ‘B’		‘C’ Armour/Braid
					Standard Seal		Alternative Seal (S)
	Metric	NPT *
		Standard	Option		Min.	Max.	Min.	Max.	Min.	Max.	Orientation 1	Orientation 2		Across Flats	Across Corners
Os	M20 ‡	½"	-	15	3.0	8.0	-	-	5.5	12.0	0.8 / 1.25	0 / 0.8	52.0	24.0	26.5
O	M20 ‡	½"	-	15	6.5	11.9	-	-	9.5	16.0	0.8 / 1.25	0 / 0.8	52.0	24.0	26.5
A	M20	¾"	½"	15	10.0	14.3	9.0	13.4	12.5	20.5	0.8 / 1.25	0 / 0.8	53.0	30.0	32.5
B	M25	1"	¾"	15	13.0	20.2	9.5	15.4	16.9	26.0	1.25 / 1.6	0 / 0.7	59.5	36.0	39.5
C	M32	1¼"	1"	15	19.5	26.5	15.5	21.2	22.0	33.0	1.6 / 2.0	0 / 0.7	64.0	46.0	50.5
C2	M40	1½"	1¼"	15	25.0	32.5	22.0	28.0	28.0	41.0	1.6 / 2.0	0 / 0.7	68.3	55.0	60.6
D	M50	2"	1½"	15	31.5	44.4/42.3 †	27.5	34.8	36.0	52.6	1.8 / 2.5	0 / 1.0	79.0	65.0	70.8
E	M63	2½"	2"	15	42.5	56.3/54.3 †	39.0	46.5	46.0	65.3	1.8 / 2.5	0 / 1.0	78.4	80.0	88.0
F	M75	3"	2½"	15	54.5	68.2/65.3 †	49.5	58.3	57.0	78.0	1.8 / 2.5	0 / 1.0	83.7	95.0	104.0
G	M80	3½"	-	20	67.0	73.0	-	-	75.0	89.5	2.0 / 3.5	0 / 1.0	95.6	106.4	115.0
H	M90	3½"	-	20	67.0	77.6	-	-	75.0	89.5	2.0 / 3.5	0 / 1.0	95.6	115.0	130.0
J	M100	4"	-	20	77.0	91.6	-	-	88.0	104.5	2.5 / 4.0	0 / 1.0	95.6	127.0	142.0
All dimensions in millimetres (except*). Os - F size metric entry threads are 1.5mm pitch as standard. For G size Cable Glands and above, a 2mm pitch is supplied as standard (1.5mm pitch with 15mm length of thread can be supplied) please specify when ordering. † Smaller value is applicable when selecting reduced NPT entry option. Sizes Os and O are available with an M16 thread size. For O size with an M16 thread, the maximum cable inner sheath diameter is 10.9mm.
