管夹阀 进口电动管夹阀价格

进口电动管夹阀  Electric Pinch Valve
进口电动管夹阀是以电动装置为驱动源，来对阀门进行开启和关闭，可以实现远程控制的管夹阀
Imported electric pipe clamp valve uses electric device driver source, to open and close the valve, can realize the remote control of the pipe clamp valve,
进口电动管夹阀结构组成由电动执行器、左右铸铁、碳钢、不锈钢阀体、橡胶管套、大小阀杆、闸板、上下导柱等零件组成。
Imported electric pipe clamp valve structure composed of electric actuator, cast iron, carbon steel, stainless steel or rubber sleeve, valve body, valve, gate size, upper and lower guide pillars and other parts.
电源电压 AC220±10%，50HZ   The power supply voltage AC220 ± 10%, 50HZ
耗电功率（额定负载时）  Power consumption （ rated load ）
格A型执行器 50VA；规格B型执行器 150VA；规格C型执行器 220VA
A type 50VA actuators; specifications of B 150VA actuators; specifications of C actuator 220VA
输入信号 DC4～20mA或 输出信号 DC4～20mA（负载电阻500Ω以下）或DC1～5V
The input signal of DC4 ~ 20mA or DC4 ~ 20mA output signal （ the load resistance is less than 500 ） or DC1 ~ 5V
基本误差：±1% ；回差≤1% ；死区≤1%  The basic error:± 1%; error≤ 1% dead≤ 1%;
工作行程调整范围 “零点”±25%；“行程”20%～100%
Working stroke adjustment range of " zero "± 25% " travel " from 20% to 100%;
防护等级 IP55  Protection class IP55
隔爆等级 Exd II BT4  Explosion-proof grade Exd II BT4
过载保护 规格A、B型执行器可任选，规格C型系列执行器必配
Overload protection specifications A, B actuators can be optionally, specifications of C series actuators must match
产地：德国  Origin: Germany
产品品Pai：德国Orsen奥尔申 The product brand: German Orsen
德国奥尔申电动管夹阀优点  The German OHL Shen electric pipe clamp valve advantages
采用进口先进的电动执行器，电压有220V,380V，电动执行器扭矩大，反应快，噪音低，使用寿命长，可实现无人远程控制，实现作业效率。
Imported electric actuator advanced, voltage is 220V, 380V, electric actuator torque, quick response, low noise, long service life, can realize unmanned remote control, to achieve operating efficiency.
