| 类型 | 数字示波器 | 品Pai | 美国力科 |
| 型号 | WaveSurfer 62MXs-B | 通道数 | 4 |
| 带宽 | 600（MHz） | 是否提供加工定制 | 否 |
| Vertical System | |
| Bandwidth | 600 MHz |
| Rise time | 500 ps |
| Input Channels | 4 |
| Bandwidth Limiters | 20 MHz, 200 MHz |
| Input Impedance | 1 MΩ ± 1.0% || 16 pF ± 2 pF, 50 Ω ± 1.0% |
| Input Coupling | AC, DC, GND |
| Maximum Input Voltage | 1 MΩ: ± 250 Vpk, 50 Ω: 5 VRMS |
| Channel-Channel Isolation | ≥ 52 dB at 100 MHz ≥ 30 dB at 600 MHz |
| Vertical Resolution | 8 bits |
| Sensitivity | 1 MΩ: 2 mV/div - 10 V/div 50 Ω: 2 mV/div - 1 V/div |
| DC Gain Accuracy | ±1.5% |
| Offset Range | ±1 V: 2 mV/div - 99 mV/div ±10 V: 100 mV/div - 1.0 V/div ±100 V: 1.02 V/div - 10 V/div |
| Horizontal System | |
| Time/Division Range | 200 ps/div - 1000 s/div |
| Clock Accuracy | 5 ppm |
| Trigger and Interpolator Jitter | 3 ps (rms) |
