“蓄电池备电+移动油机应急发电”是有市电区域Z基本的基站后备动力保障配置方案。对于频繁需要上站应急发电的基站叠加小功率太阳能系统，可大幅降低应急发电成本，并持续获得电费节省，投资回报周期小于3年。传统叠光方案存在太阳能利用不充分、影响电池充电管理等问题，采用兼容太阳能输入的开关电源系统叠光，可以低成本实现高收益。支持叠光的

通信电源系统有利于在运维期间动态调整配置，针对应急发电上站次数较多的基站实施叠光，能Z小化叠光投资，在提高动力保障的同时长期节省电费和应急发电成本。

一、电池和应急发电问题多，成为断站因素

随着互联网快速发展，人们生活已经离不开网络，需要无处不在的移动宽带。基站稳定运行是通信网络高可用的基础，由于停电不可避免，基站需要有合理的后备动力保障方案。蓄电池+移动油机是Z常用的后备动力保障方式，停电时由蓄电池支持基站工作，当蓄电池容量不足时，调派移动油机上站发电，保障基站运行不中断。

由于居民对噪声的普遍反对，以及站点所在建筑物出入管理原因，实际上城市站点很难上站应急发电；农村站点发电距离远、高山站上站困难，应急发电保障度困难。通过对基站通信中断原因分析，平均57%网络中断与基站配套相关，停电是引起网络中断的要因。

以某市某运营商3453个站点为例，高山站无法应急发电的有195个，业主原因经常无法上站发电的有2004个，无法用移动油机保障的站点占比高达64%。该运营商单月停电2771站次，由于停电原因发生断站1923次，停电断站率高达69%。停电断站涉及1322站点，平均每站断站时长高达2.1小时。应急发电次数802次，停电发电比例29%，其中包括40次应急发电不及时导致基站运行中断。由此可见，停电后不能应急发电或应急发电不及时是造成通信网络中断的因素。

二、蓄电池+移动油机，后备动力保障成本很高

在基站容量一定的条件下，蓄电池容量取决于后备时长要求，后备时长必须大于应急发电上站时间，并留有足够的余量。对于频繁停电的基站，如果具备小型固定油机安装条件，可安装固定油机，不具备固定油机安装条件的基站，适当增配电池，如郊县、农村、山区备电时长可分别增至5、7、10小时。对于通信负载平均功率为2kW的站点，备电7小时需要配置一组500Ah蓄电池，电池成本很高。移动油机作为应急保障电源，停电时安排发电人员上站发电，即使应急发电人员尚未到达站点时市电已恢复，也需要支付应急发电费用。

应急发电成本包括上站人工费用、发电油费、移动油机摊销成本。上站人工费用与当地劳动力成本相关，一般在300元/次左右；发电燃油成本与发电时长、耗油率相关，一般平均每次发电消耗50元左右燃油；移动油机摊销成本包括油机折旧、油机维护成本分摊，平均每次发电分摊30元左右。农村站点是停电高发区域，平均月上站次数可能超过一次，按应急发电成本每次380元计，如果每月发电一次，每年单站应急发电成本4560元，发电成本很高。

减少停电断站、提高通信网络质量是通信动力系统建设与维护的要务。不论是增配蓄电池延长备电时长、提高应急上站发电次数、安装固定油机等，都可以降低停电断站率，提高通信网络质量。由于蓄电池成本很高，增加1小时备电时长平均每站每年需要投入400元左右；每增加1次应急上站发电需增加380元左右；安装固定油机一次性投入成本很高。不论是电信运营商还是铁塔运营商，都需要有以较低成本提高保障质量的解决方案。

三、站点叠光，低成本提高供电质量、降低运维成本中兴ZXDU58 W600 V4.5R01M01室外壁挂式电源柜

站点叠光方案，指在站点电源基础上叠加太阳能，安装仅满足通信负载功率需求的太阳能电池板，优先使用太阳能供电的方案。太阳能是可再生能源典型代表，叠加太阳能可降低站点电费。例如，对于平均直流负载功率为2kW的站点，假设日照时数为4小时（全国省会城市贵阳2.84小时、拉萨6.7小时，一半以上超过4小时），采用叠光方案可年省电2920度，需要安装约2.5kWp的太阳能电池板。客户采购太阳能电池板、太阳能模块及其安装服务成本为22000元，如果电价为1元/度，则叠光方案的投资回报周期为7.5年左右，决策投资相对困难。

叠光后，如果基站停电发生在有日照的时段，可以不需要应急发电。由于深夜通信业务较少、夜晚上站发电相对危险等因素，实际很少夜间发电。此外，由于移动油机普遍不防雨且室内发电危险，雨天一般也不发电。因此，应急发电多在没有下雨的白天进行，该时间段太阳能可用概率很高，即使阴天太阳能发电量很少，也可延长电池备电时长。经过测算，采用叠光方案的站点，可以减少80%以上上站应急发电成本，并降低由于应急发电不及时带来的断站风险。

例如，某市某运营商共432个基站，2014年12月份发电77次，只有一次为夜间发电，发电次数TOP 10基站平均发电15.64小时，平均发电次数3.8次，Z长一次发电时长仅5.42小时，发电时长相对平均。在相同应急保障条件下，对于应急发电TOP 10站点具备安装太阳能电池板条件的，可采用叠光措施，假定减少应急发电次数比例为80%，单站一个月可以节省上站费用1155元。由于12月份并非停电高峰，评估单站一年可节省1.4万元以上发电费用，远比省电价值更大，投资回报周期仅1.3年左右。如果批量采用叠光方案，还可能获得国家和地方政府财政补贴，如浙江省对于太阳能发电量每度补贴0.42元，可以进一步降低投资回报周期。由于应急发电成本以人工费用为主，人工费用呈长期上升趋势，随着应用时间的增加，叠光方案回报越来越高。

3~5年是合理的投资回报周期，按示例，叠光方案总投资2.2万元，只要每年节省超过4400元，就值得投资。一个2kW站点年省电按2920元计，只需要能年节省1480元应急发电费用即可满足5年投资回报要求。按每次发电成本380元计，对于年上站应急发电需求4次以上的站点，都值得投资叠光方案。如果太阳能发电可获得补贴，如0.42元/度，每年补贴1226元，加之站点都或多或少存在应急发电需求，对所有具备安装太阳能条件的站点普遍叠光，会具备非常好的投资回报。一个单运营商2G/4G站点或两个运营商单制式共享站典型负载平均功率接近2kW，可配置一个3kW太阳能模块和9×250Wp太阳能电池板，只需要净占地面积13平米。当安装面积不足时，可以欠配安装，如只安装1.5kW太阳能电池板，停电时不足的功率由电池补充,使原来只能备电3小时的站点（300Ah电池）在阳光较好时备电时长延长至12小时以上，同样能大幅减少应急发电次数。

四、传统叠光方案，电池管理风险需要谨慎控制

传统叠光方案指在站点内增加一套独立的太阳能系统，太阳能模块输出的直流电直接与存量开关电源直流输出并联，太阳能系统与开关电源互相独立。由于需要优先使用太阳能，太阳能系统输出的开路电压应高于开关电源。对于传统叠光方案来说，太阳能系统输出电压设置非常关键，不合适的设置会导致部分甚至全部太阳能被浪费。当开关电源或太阳能系统电压测量电路出现偏差时，也可能发生同样的结果。此外，开关电源均充时，由于电源输出电压更高，这段时间内太阳能无法被利用。

开关电源具备蓄电池管理功能，能限制充电电流以保护蓄电池使用寿命。当太阳能系统输出电压高于设置值时，过高的电压使电池过充。由于叠加的太阳能功率大于负载功率是常态，在蓄电池需要充电时，多余的太阳能功率也会对电池进行充电，使电池充电电流大于开关电源设定的充电限流值，蓄电池实际充电电流与开关电源系统测量值不一致，不利于蓄电池充电管理。

开关电源都有温度补偿功能，电池温度补偿范围为±2V，由于开关电源温度补偿功能无法与太阳能系统关联，温度降低时电源浮充电压升高，导致太阳能浪费，而温度升高时太阳能输出电压不变，使电池加速充电失水。如果取消开关电源温度补偿功能，太阳能可以得到充分应用，但会影响蓄电池使用寿命。

为了充分利用太阳能，保护电池寿命，对于传统叠光方案需要准确配置太阳能电池板数量，谨慎设置太阳能系统和开关电源电压，并取消电池温度补偿功能，在温度变化不大的室内站点使用。

五、电源兼容太阳能，消除电池管理风险

随着电力电子技术与数字信息技术融合发展，电源模块控制芯片内含软件和算法，使硬件功能可由软件定义，称为软电源（SDP，Software Defined Power），可以很方便地实现不同功能模块兼容。太阳能模块与整流模块兼容就是典型的软电源特性，采用兼容太阳能的开关电源系统，就能在任何合适的站点在电源模块位置插入太阳能模块，不需要采购独立的太阳能控制系统，除了太阳能电池板采购及安装费用外，只需要从开关电源厂家购买一个太阳能模块即可。

由于太阳能模块与整流模块兼容，通过同一个监控模块控制，不论太阳能功率大小，也不论蓄电池需求电压高或低，都会优先调度使用太阳能，使太阳能全部得到利用。太阳能模块和整流模块的输出电压统一控制，并与中兴ZXDU58 W600 V4.5R01M01室外壁挂式电源柜电池温度补偿同步，蓄电池充放电管理功能完全不受影响。山西铁塔联合华为试点MTS站点电源叠光，叠光工程量就是安装太阳能电池板的工作量，系统不需要调试就成功投产。因此，部署站点时宜优选支持叠光功能的电源系统，引导全行业电源向多功能兼容方向发展。对于存量宜叠光站点，如果存量电源不是GX电源且无法直接替换GX模块，优先采用多功能GX电源改造。

六、应急发电TOP N管理，实现低成本叠光

由于站点规划建设时很难预测未来应急发电情况，对于投产后的站点可以采用基于短板改进的应急发电次数TOP N管理手段，通过站点网管系统对应急发电次数进行统计，选择应急发电次数多、合适安装太阳能电池板的站点进行叠光，可以实现JZ配置，Z小化叠光成本。如山西试点的叠光站点就是停电次数较多的站点，经测算，站点叠光年收益高达2.1万元/年，非常可观。

如果全面采用支持叠光的电源系统，定期对区域内基站应急发电次数TOP N站点进行叠光、叠油（不具备安装太阳能条件，但可安装固定油机的）、叠电（对于不能叠光、叠油的站点，可直接增配新电池或锂电池）等手段优化，逐渐消灭需要频繁应急发电的站点，大幅度减少应急发电上站次数，降低应急发电成本，并在节能的同时提高基站可靠性。到目前为止，叠光是以较低成本实现站点供电高保障的方案。

"Battery preparation +

mobile oil engine emergency power generation" is the most basic backup power support configuration of base station in the city. For the base stations that frequently need to go to the station for emergency power generation, the small power solar system can be superimposed, ａnd the cost of emergency power generation can be greatly reduced, ａnd the electricity cost will be continuously saved. The investment return cycle is less than 3 years. Traditional stacking scheme has many problems, such as inadequate solar energy utilization ａnd influence on battery charging management. The switching power supply system compatible with solar input can achieve high cost at low cost. The communication power supply system supporting stacking light is conducive to dynamically adjusting the configuration during operation ａnd maintenance. It can reduce the cost of light investment for the base stations which are more frequent on the basis of emergency power generation, ａnd minimize power overlay investment. At the same time, it can save electricity ａnd emergency power generation cost at the same time.

One, battery ａnd emergency power generation problem, become the first factor of fault station

With the rapid development of the Internet, people can not live without the network, ａnd it needs ubiquitous mobile broadband. The stable operation of the base station is the foundation of the high availability of the communication network. Because of the inevitable blackout, the base station needs a reasonable backup power support scheme. Battery + mobile oil machine is the most commonly used backup power support mode. When the power fails, the battery will support the base station. When the battery capacity is insufficient, the mobile oil station will be dispatched to the station to generate electricity, so that the base station will run without interruption.

Because of the widespread opposition to noise ａnd the reasons for the access ａnd management of buildings in the site, it is very difficult for the urban station to go to the station for emergency power generation. The rural station is far away from the power station, ａnd the station on the high m中兴ZXDU58 W600 V4.5R01M01室外壁挂式电源柜ountain station is difficult, ａnd the emergency generation support is difficult. Through the analysis of the reason for the interruption of the base station communication, the average 57% network interruption is related to the base station, ａnd the blackout is the first cause of the network interruption.

Take 3453 operators of a certain city as an example, there are 195 stations that can＇t generate electricity by emergency at Gaoshan station, ａnd 2004 of them cannot afford to go to station because of owners＇ reasons. The proportion of stations that cannot be protected by mobile oil machine is 64%. The operator single month outage 2771 times, due to power outages cause broken station 1923 times, power station fault rate is as high as 69%. The blackout station involves 1322 stations, ａnd the average height of each station is up to 2.1 hours. Emergency power generation 802 times, power generation ratio of 29%, including 40 emergency power generation is not timely lead to the base station operation interruption. So it can be seen that the failure of emergency power generation or emergency power generation after blackout is the first factor that causes the interruption of the communication network.

Two. Battery + mobile oil machine, the cost of backup power is very high

Under the condition of certain capacity of the base station, the capacity of the battery depends on the reserve time requirement, ａnd the reserve time must be larger than the emergency power generation time, leaving enough margin. The base station for the frequent power outages, if you have a small fixed oil machine installation conditions, can be installed ａnd fixed oil machine, do not have the conditions of fixed base station installation of machine oil, properly equipped with batteries, such as suburban, rural ａnd mountainous areas by time can be increased to 5, 7, 10 hours. For a station with an average power of 2kW for the communication load, a set of 500Ah batteries should be configured for 7 hours, ａnd the cost of the battery is very high. The mobile oil as an emergency power supply, when the power is cut off, the generator will be sent to the station to generate electricity. Even if the emergency generator has not arrived at the site, the electricity has been recovered, ａnd the emergency power generation cost should be paid.

The cost of emergency power generation includes the labor cost of the station, the cost of power generation oil, ａnd the amortization cost of the mobile oil machine. On labor costs associated with local labor costs, generally about 300 yuan / times; the cost of fuel ａnd power generation time, fuel consumption rate, the average power consumption per 50 yuan fuel; mobile oil machine including machine depreciation, amortization cost of oil ａnd oil machine maintenance costs, the average power allocation of 30 yuan. The rural station is a high power failure area. The number of stations on average may exceed one time per month. According to the emergency power generation cost, 380 yuan per time. If the electricity is generated once a month, the annual single station emergency power generation cost is 4560 yuan, ａnd the cost of generating electricity is very high.

中兴ZXDU58 W600 V4.5R01M01室外壁挂式电源柜the high cost of battery, the increase of 1 hours, the average power consumption time is about 400 yuan per station per year. For every 1 increase, the power generation for emergency stations needs to increase by about 380 yuan, ａnd the cost of installing fixed oil units is high. Both telecom operators ａnd tower operators need solutions to improve the quality of the guarantee at a lower cost.

Three, site stacking, low cost to improve the quality of power supply ａnd reduce operation ａnd maintenance costs

The site overlay scheme refers to the solar panels that are installed on the site power supply ａnd only meet the power demand of communication load. Solar energy is a typical representative of renewable energy, ａnd the superposition of solar energy can reduce the electricity cost of the site. For example, the average DC load power for the 2kW site, assuming the sunshine hours for 4 hours (the capital city of Guiyang, Lhasa＇s highest minimum 2.84 hours 6.7 hours, more than half of more than 4 hours), the scheme can stack light annual saving 2920, need to install about 2.5kWp solar panel. The cost of customer purchasing solar panels, solar modules ａnd installation services is 22000 yuan. If the electricity price is 1 yuan / degree, the investment return period of the scheme is about 7.5 years, making investment decisions relatively difficult.

After stack light, if the base station blackout occurs in the period of sunshine, there is no need for emergency power generation. Because of the low night communication service, the night is on the station。

数据ZX是我国实施“互联网+”的重要基础设施载体。相关统计显示，截至2014年年底全国共规划建设数据ZX310个，已投入使用230个，其中约有三分之一为大型数据ZX。另据数据ZX产业联盟发布的《数据ZX产业发展白皮书》显示，2011~2016年我国数据ZX总投资将超过1万亿元。其中高低压供配电、不间断电源、制冷系统等配套设施造价在基础设施造价中所占比例约75%~80%。

大型数据ZX建设热潮来袭。然而，在大型数据ZX的运营中，巨大的配电成本支出正在对运营商形成挑战，同时配电单元往往占用大量面积，不利于数据ZX的节能环保。因此，如何能够在保证数据ZX稳定运行的情况下，实现配电系统的革新，显著降低配电成本成为业界关注的问题。正是在这一趋势下，中压型UPS开始兴起。中压型UPS能够提高接近负荷ZX的电压等级，减少低压配电环节，降低能耗。可以预见，随着电信行业去电信化、减配增效的深入推进，中压UP中兴ZXDU58 W600 V4.5R01M01室外壁挂式电源柜S系统将迎来广阔的市场前景。

大型数据ZX低压配电系统亟待革新

我国早期通信系统负有政治安全责任，通信网络一旦中断将追究相关方政治责任，所以我国通信系统中冗余配置较高，这从早期UPS和开关电源蓄电池组后备时间的不一致可见一斑。所以，在建设数据ZX的供电系统时，为了保证系统安全可靠性，充分考虑设备配置和冗余。

目前大型数据ZX园区或大型数据ZX的供配电结构一般是引市电高压（110kV）或中压（35kV、10kV）到高压配电室然后再分配给干式变压器（转成380V）并配置成套低压配电系统，成套低压配电系统中的馈电柜再通过密集母线或电缆分配电能到每个楼层的低压配电柜，再分配到大型的UPS（如500kVA、600kVA），目前每套低压配电系统一般配置到2000kVA，每套低压系统Z多带两套大容量的1+1型UPS系统或2N型UPS系统，这种从高压配电系统-低压配电系统-UPS的结构在早期中小型数据ZX应用广泛，但随着数据ZX单UPS系统配电容量的加大，这种配电结构存在诸多缺陷。

，投资浪费严重。单套低压配电系统存在浪费投资、浪费机房空间、浪费密集母线等浪费现象。虽然也可以将变压器配置在每个楼层，但是供配电结构没有变化，随着大型UPS的使用，每套2000kVA的低压配电系统下挂2套600kVA（1+1）考虑充电电流及负载冗余后即满。

第二，增加供配电等级，增加了安全隐患。在相同的电源器件环境中，对于配电系统来说上下游开关越少越安全，配电等级越少可靠性越高，接近负荷ZX的电压等级越高越节能。大型数据ZX园区35kV开关站-10kV高压配电柜-10kV配电柜-变压器-低压配电柜-密集母线-楼层配电柜-UPS系统，8层级的配电结构，每多1个层级则意味着增加一个故障隐患点。

第三，影响机房可使用面积，增加建筑成本。对于大型数据ZX，如果每层楼均配置变压器低压配电室、UPS系统电源室，相应电源区域要预留40%以上的空间，对于通信机房来说，一般预留25%~30%空间，且低压配电结构冗余度越大占机房面积越大。

中压型一体化UPS正在兴起

回顾通信领域的高低压配电发展趋势，交流系统从早期的380V到中兴ZXDU58 W600 V4.5R01M01室外壁挂式电源柜10kV，不间断电源从220V到240V、336V高压直流，设备功耗密集程度越大配电系统的电压等级也随之上升，采用高压等级的设备可以更多地减少线损、线缆母线投资、节省设备占地面积、减少转换次数也意味着节能，同样，改变传统的380V进380V出220V配电的结构，提高UPS进入电压等级至10kV以上也具备以上优点。使用如10kV的UPS的前提是将传统低压配点系统的计量功能、功率补偿功能、低压发电机组转移到10kV系统。

低压配电中的计量可采用高压端计量。传统数据ZX往往是通过在低压段低压配电系统中配置计量柜的方式，但是随着数据ZX规模越来越大，大型数据ZX已有10套以上的低压配电系统，且分为生活用电、办公用电等，统计量工作放在高压将成为一种趋势。采用高压端计量的同时仍可以通过中压型一体化UPS的变压器的数据采集进行自动统计上报。

低压配电中的补偿功能可改为高压补偿和负荷ZX就近补偿。对于数据ZX来说，感性负载和容性负载同时存在，感性负载主要为空调主机、风机等电机类设备；整流设备、IT设备为容性负载；也就说数据ZX感性负载和容性负载是同时存在的，是相互补充的。统计显示，目前大部分通信局楼的低压电容器柜多设置为人工投入，因为由于感性负载和容性负载的同时存在，功率因数cosΦ通常都在0.92以上。采取在低压配电系统进行补偿属于后补偿，没有起到有效作用，且在谐波环境下容易引发电容器共振并存在爆炸风险。因此未来的数据ZX应针对具体机房环境测试其谐波和无功负荷情况进行就近补偿。

大型数据ZX采用高压油机是必然趋势。目前大型、超大型数据ZX已推广采用高压油机，带来很多优势：电缆、上下游开关配置方面，简化了配电结构，高压油机使用高压电缆传输电力，高压输电电流相当于低压输电电流的二十六分之一，上下游开关及电缆投资节省、敷设及施工方便、线损很小、安全性也较高；便于进行多机并机，形成大容量后备电源，消除了常压油机系统面临的输出容量瓶颈；若采用高压空调必须采用高压油机，离心机组启动电流较大，如国内某运营商集团企业标准规定“除变频供电的电动机外，单台额定功率大于350kW 的电动机，宜采用10kV 电源供电”。采用高压冷水机组供电后，可以相应减少变压器及低配和密集母线、电缆的投资，综合对比高压冷水机组的价格因素，初步统计可以节省0.075万元/kW（制冷量）；高压油机集中布置，可以根据园区功耗发展情况分期、逐台投资，而低压油机则只能是与低配模块化相匹配而无论油机的实际负载率，造成油机投资浪费；推广使用高压油机之后低压配电系统中的ATS柜可以减配。

以上分析证明，低压配电系统中的主要功能，计量、电容、ATS柜等都可以代替，实施高压到负荷ZX的二级转换比再经过低压侧显然可以节省更多成本，减少中间配电环节后也使得可靠性提高很多。

国外中压UPS系统应用现状

从欧洲地区的中压UPS系统发展来看，中压UPS系统多应用在工业级不间断电源应用场景中，拥有兆瓦级额定功率和高达99.5%的中压UPS，储能和逆变器依然处于低压水平，它还能大幅简化维护作业和降低系统成本。中压UPS可进行改造，进行定制化设计，可兼容各种各样的储能装置，具体取决于所需的保护时间。超级电容器和飞轮可在几秒钟内提供高密度保护，而电池可以达到长达15分钟的备用时间。

北美地区早期工业用中压型UPS系统多为集装箱式结构或露天箱体结构。数据ZX使用的中压型UPS系统多为户内型、模块化结构，容量为2.0MW~20MW。包括输入输出开关柜、变压器箱、主控单元、PES柜（中压）、双向变流器、储能箱等。户外型储能箱后备时间为1~3分钟，户内型后备时间根据客户需求配置，可以达到30分钟以上。

可以看到，国外已有类似产品，但是国外的中压UPS较多定位于将UPS系统功能集中于中压段解决，目前已在美国的部分大型数据ZX开始应用。

尤为值得一提的是，相比传统低压UPS，中低压一体化UPS在同样的场景下将减少80%的投资成本，而之所以能够带来这一“不可思议”的改变，则主要得益于大幅减少了传统低压配电柜的占地面积，节省了大量的低压配电母线、电缆，同时发电机组采用高压油机也便于分期投资。可以预见，中压UPS系统的建设将为运营商节省大量的供配电成本，进一步提升运营商的市场竞争力。
