深圳森东宝供应 射频探针Model 7 and Model 7A 美国GGB探针代理商

产品信息
model 7 自带射频线缆，频率范围：DC-7GHZ ；
针尖可替换，以下有model 7 替换探针的具体型号。
 PICOPROBE® MODEL 7 was designed as a companion probe to Models 12C ａnd 18C for driving integrated circuit lines so the Model 12C ａnd 18C can be used to measure the response of adjacent nodes. The Model 7 consists of a flexible 6 foot, 50 ohm coaxial cable accurately terminated to 50 ohms in order to avoid undesirable reflections. A special miniature connector receives replacement coaxial probe tips that provide a shielded environment to within 3 mm of the fine tungsten probe point, thus minimizing capacitive coupling to other parts of the circuit. The replaceable coaxial probe tips are offered in various point sizes ａnd can also be bent to any shape in order to accommodate a variety of probing geometries.
PICOPROBE® MODEL 7A



High Temperature Option

For elevated temperature applications up to 200 degrees C., Picoprobe® Models 7-HT ａnd 7A-HT can be used in place of the Model 7 ａnd 7A, respectively. Models 7-HT ａnd 7A-HT use special temperature resistant probe tips that provide accurate test results under extreme conditions.



Model 7 ａnd Model 7A Replacement Tips（替换探针型号）
Part
Number		 Tungsten Probing Wire
Shaft Diameter		 Point Radius
7-5 5 micron <0.1 micron
7-10 10 micron <0.1 micron
7-22 22 micron <1.0 micron
7-35 35 micron <2.0 micron
7-60 60 micron <3.0 micron
7-125 125 micron <5.0 micron
7-175 175 micron <5.0 micron
